brinell hardness tester autobrin3000z for steel products Sinowon
Model:
QB-500
Code#:
838-390
Warranty:
12 month
Delivery Time:
15-30days
Standard:
GB/T4340, ISO6506/6507，ASTM E10-12/E92 JIS Z2243
Certificate:
CE
Product Comparison
Sinowon carries out strict quality monitoring and cost control on each production link of vision measuring machine, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.Sinowon guarantees vision measuring machine to be high-quality by carrying out highly standardized production. Compared with other products in the same category, it has the following advantages.
-
v s
1. Sinowon brinell machine adopts the highest standard for the selection of raw materials.
2. Taking brinell machine into full consideration during the design, brinell hardness tester are all produced with the highest quality.
3. Furthermore, brinell hardness tester has such features as brinell machine , so it is a more perfect for the field.
4. brinell hardness tester is known as high quality and good service provided by Sinowon Innovation Metrology Manufacture Limited..
Introduction
QB-500 high accuracy Brinell optic measurement system mainly used to test accuracy of hardness block for manufacturer and verification lab, also available for specimens Brinell indentation measurement.
Features
◆ Apply telecentric zoom lens, can measurement Brinell indentation accurately on mirror surface and rough surface.
◆ High accuracy microscope stage with travel 100 x 50mm, supportt specimen weight at max 15Kg.
◆ Non-touch optical measurement, with laser navigation, easily to find indentation.
◆ By BrinScan V2.0 software, realize auto measurement.
Specification
| Name | High accuracy Brinell optic measurement system | |
| Model | QB-500 | |
| Code# | 838-390 | |
| Hardness Resolution | 0.01HB | |
| Repeatability | ±1HB | |
| Specimen Weight | 15Kg | |
| Stage Travel | 100X50mm | |
| Z Axis Travel | 50mm | |
| Z Axis Guiding | Dovetail groove and manual driven | |
| Illumination | Adjustable LED cold light source, coaxial light source | |
| Software | Brinscan V2.0 | |
| Operation OS | Win8、Win10，32/64bit；Office | |
| Working Environment | Temperature 20℃±1℃， Humidity 30~80% | |
| Voltage | 220V/50HZ | |
| Weight | 20Kg | |
| Dimension | 440x410x700mm | |
Company Features
1. Sinowon Innovation Metrology Manufacture Limited., a nation-renowned brinell machine developer and manufacturer, is known for its strong R&D and manufacturing competence in this field.
2. Sinowon Innovation Metrology Manufacture Limited. has established a scientific and standardized quality management system.
3. We are responsible for the society. Quality, environmental, health, and safety commitments are prerequisites for all our activities. These policies are always implemented using international standard methods, and all commitments are effectively implemented. Inquire online! We are committed to working with our customers to realize their sustainability goals in a safe, energy-efficient and environmentally conscious manner. Our core value is a strong teamwork spirit. We encourage not only internal teamwork, but also the cooperation across boundaries. By this way, we work better with our partners to meet their requirements which in return helps our company grow. Inquire online! Sinowon Innovation Metrology Manufacture Limited. seeks the commonality while maintaining differences with customers. Inquire online!
