excellent instant measurement system design for precision screws
- Sinowon runs the business in good faith and strives to provide quality services for customers.
1. Advanced designing techniques are adopted in Sinowon manual vision measuring machine manufacture. Advanced rapid prototyping and CAD technology have been used to produce simple and complex geometries of the furniture.
2. This product stands out for its breathability. Its materials used provide a ventilated environment that would not allow the heat and moisture to accumulate.
3. The product has been added to a level of security. People can set assured that their belongings are always safe.
Product Feature
High accuracy and excellent repeatability
◆ High depth of field, low distortion double telecentric lens, no need to repeat focus.
◆ Software processes the image by the way of Sub-pixel edge detection and automatic removal of burrs and outliers and the least-square method to ensure accuracy.
Friendly operation
◆ Automatic location and orientation correction, automatically detect and measure based on the recorded shape of the sample, measure with a click of button.
Efficient batch measurement
◆ Automatically identify multiple parts, test elements, then conduct automatic measurement, satisfied with batch measurement requirements.
◆ Entire image, no need to move the working stage, both high efficiency and high accuracy.
◆ Improve efficiency, save labor cost, eliminate operator error.
Quality Control and Statistical Process Control (SPC)
◆ Automatic memory and output measuring values, and make test data simple applied.
Technical Specification
| Model | iVS-30 | iVS-60 | iVS-80 | iVS-160 |
| Code# | 500-030 | 500-060 | 500-080 | 500-160 |
| Lens | 0.3X Double Telecentric Lens | 0.17X Double Telecentric Lens | 0.088X Double Telecentric Lens | 0.088X Double Telecentric Lens |
| Working Distance | 110 mm | 110 mm | 120 mm | 390mm |
| Wide Field | Ø 30mm(28x24) | Ø 60mm(56x50) | Ø116mm(94x76) | Ø229.6mm(146.7x110) |
| Measurement Accuracy | ±2um | ±3um | ±4um | ±7um |
| Repeatability Accuracy | ±1um | ±2um | ±2um | ±5um |
| Camera | 2/3’’ 5 million pixel B/W camera (Ethernet) | |||
| Illumination | Digital controls, automatic memory | |||
| Telecentric Green LED Contour illumination | ||||
| Ring White LED illumination | ||||
| PC System | DELL (I5 Intel processors) | |||
| Monitors | Built-in 10.4 inch LCD Monitor(1920*1080) | |||
| External 21.5 inch LCD Monitor(1920*1080) | ||||
| Measuring Software | iMeasuring 2.0 | |||
| Measuring Amount | Max.99 | |||
| Test Time | <5S (Less than 100 tests) | |||
| Output data | Test data, reports, determine the results (OK, NG, WAIT), etc | |||
| Function | 2D measurements: points, lines, circles, arcs, angles, distance, oval, O-rings, Groove, rectangle, parallelism | |||
| Auxiliary Function | Intersection, parallel, perpendicular, tangent, bisection. | |||
| Geometric Tolerances | Dimension tolerances and position tolerances, tolerances of form and position (Point position concentricity, straightness, parallelism, roundness, straightness, profile, etc) | |||
| Measurement Mode | Manual / Automation | |||
| SPC Data Management and Control | √ | |||
| CAD Data Input / Output | √ | |||
| Power Supply | AC100~240V，50~60Hz | |||
Application
It is widely used in quick batch measurement of precision screws, precision springs, gears, cell phone case, cell phone glass, precision metal parts and other parts in small size.
Product Details
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is a dynamic and fast-moving company specializing in manufacturing manual vision measuring machine. We have proven that we are one of the market leaders in China.
2. We have technologically advanced manufacturing facilities. They are incredibly flexible, fully-automated, and computer-driven, allowing us to produce products precisely to the required specifications.
3. Sinowon hopes to bring customers with best user experience for instant measurement system . Get quote! Sinowon highly values details for whatever quality or service. Get quote!
