Sinowon automatic Vision Measuring Machine inquire now for small parts

Company Advantages
1. Sinowon vickers hardness test experiment is in compliance with recognized safety standards. These standards are usually in the form of test reports from recognized testing laboratories.
2. Its long service life is greatly ensured by the strict testing procedure.
3. This timeless design product is not likely to go out of date in people's wardrobe. It will definitely bring style and a bit of uniqueness to people's wardrobe.

◆ Hardness testing of metals and scientific researching;

◆ Hardness range from soft materials to very hard materials;

◆ Except very thin and coated layers, can test almost the metals.

◆ Apply closed loop loading sensor, MPU controls the loading, dwell and unloading process;

◆ Equips with LCD screen, show loading force, hardness value, dwell time;

◆ Just aim the dialog line, then it will automatically reading the length and display hardness value

◆ Available to add optional mini printer, motorized turret, and VicPad measurement device or PC software iVicky 2.0.

Product Name		Digital Vickers hardness tester
Model		SV-5	SV-10	SV-30	SV-50
Code#		821-101S	821-111S	821-121S	821-131S
Loading Force	N	2.94、4.9、9.8、19.6、24.5、29.4、49.0	2.94、4.9、9.8、19.6、24.5、29.4、49.0、98.0	4.9、9.8、19.6、24.5、29.4、49.0、98.0、196、294	9.8、19.6、24.5、29.4、49.0、98.0、196、294、490
	Kgf	0.3、0.5、1、2、2.5、3、5	0.3、0.5、1、2、2.5、3、5、10	0.5、1、2、2.5、3、5、10、20、30	1、2、2.5、3、5、10、20、30、50
Optic System		Observe and Measure Objectives：10X/20X	Observe and Measure Objectives：10X/40X	Observe and Measure Objectives：10X/20X	Observe and Measure Objectives：10X/20X
Hardness Range		1HV-2967HV
Turret		Manual Turret（Optional Motorized Turret）
Loading Control		Auto loading dwell and unloading
Eyepiece		10x digital Eyepiece
Dwell Time		5-60s adjustable
Illumination		LED / halogen
Vertical Space		170mm
Horizontal Space		130m
Power Supply		AC220V/50Hz; AC110V/60Hz
Tester Dimension		530x225x630mm
Packing Dimension		630x460x710mm
Gross / Net Weight		75Kg/55Kg
Conform Standards		ISO6507，ASTM E92，JIS Z2244，GB/T4340

Company Features
1. With a long history, the products and technology of Sinowon Innovation Metrology Manufacture Limited. are in a leading position.
2. Our factory has the most efficient manufacturing machines. They can serve to streamline the production process, improve production efficiency, and produce better quality products.
3. By strictly complying with environmental obligations, we ensure that the use of energy, raw material, and natural resources are legal and environmentally friendly. We work hard to minimize our impact on the environment and develop a sustainable footprint. We continuously find environmental ways to reduce energy consumption, eliminate waste, and reuse materials. We have made a feasible goal: to increase the profit margin through product innovation. Except for the development of new products, we will improve the performance of the existing products based on customers' needs.
