Sinowon hot selling brinell hardness tester manufacturer for cast iron
Model:
QB-500
Code#:
838-390
Warranty:
12 month
Delivery Time:
15-30days
Standard:
GB/T4340, ISO6506/6507，ASTM E10-12/E92 JIS Z2243
Certificate:
CE
Enterprise Strength
- Sinowon insists on the principle to be honest, practical, and efficient. We continue to accumulate experience and improve service quality, so as to win praise from customers.
Product Details
Sinowon's hardness testing machines is of exquisite workmanship, which is reflected in the details.Sinowon provides diversified choices for customers. hardness testing machines is available in a wide range of types and styles, in good quality and in reasonable price.
1. Continuously improved management system makes sure the production process of Sinowon brinell hardness test equipment runs smoothly and efficiently.
2. This product is methodically examined to ensure the quality and durability.
3. The product quality is doubly guaranteed by professional QC team and sophisticated testing equipment.
4. This product will finally contribute to bringing profits for manufacturers. It helps cut expenditures both in labor and energy consumption.
Introduction
QB-500 high accuracy Brinell optic measurement system mainly used to test accuracy of hardness block for manufacturer and verification lab, also available for specimens Brinell indentation measurement.
Features
◆ Apply telecentric zoom lens, can measurement Brinell indentation accurately on mirror surface and rough surface.
◆ High accuracy microscope stage with travel 100 x 50mm, supportt specimen weight at max 15Kg.
◆ Non-touch optical measurement, with laser navigation, easily to find indentation.
◆ By BrinScan V2.0 software, realize auto measurement.
Specification
| Name | High accuracy Brinell optic measurement system | |
| Model | QB-500 | |
| Code# | 838-390 | |
| Hardness Resolution | 0.01HB | |
| Repeatability | ±1HB | |
| Specimen Weight | 15Kg | |
| Stage Travel | 100X50mm | |
| Z Axis Travel | 50mm | |
| Z Axis Guiding | Dovetail groove and manual driven | |
| Illumination | Adjustable LED cold light source, coaxial light source | |
| Software | Brinscan V2.0 | |
| Operation OS | Win8、Win10，32/64bit；Office | |
| Working Environment | Temperature 20℃±1℃， Humidity 30~80% | |
| Voltage | 220V/50HZ | |
| Weight | 20Kg | |
| Dimension | 440x410x700mm | |
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is a modernized globally leading integrated brinell hardness tester company.
2. Sinowon Innovation Metrology Manufacture Limited.'s production technology is parallel to world class technology.
3. We have set our operational principles. We place an extremely strong focus on rapid response to our customers – turning speed and agility into a key competitive advantage. We have been maintaining the principle of environmental responsibility to partake in environmental conservation and management. For example, we require the production team to store or discharge waste safely and legitimately.
