Sinowon macro Vision Measuring Machine with good price for small parts

Model:
V-5
Code#:
821-101
Warranty:
12 month
Delivery Time:
15-30days
Standard:
ISO6507,ASTM E92,JIS Z2244,GB/T4340
Certificate:
CE
Inquiry
Product Comparison
Sinowon has the ability to meet different needs. hardness testing machines is available in multiple types and specifications. The quality is reliable and the price is reasonable.Sinowon's hardness testing machines has better quality than other products in the industry, which is specifically shown in the following aspects.
  • Sinowon macro Vision Measuring Machine with good price for small parts 3
    Sinowon macro Vision Measuring Machine with good price for small parts 4
Company Advantages
1. Different quality tests for Sinowon vickers microhardness conversion have been carried out in the final production stage. These tests are an anti-aging test (ASTM D573), colorfastness to rubbing (AATCC 8), structural tearing strength or rigidity (SATRA TM30), etc.
2. This product is strong and robust. It has a well-made frame that will allow it to maintain its overall shape and integrity.
3. The product is characterized by precise dimensions. At the very beginning stage of pattern making, its sizes have been controlled within a very limited tolerance.
4. Containing zero methanal or other chemical materials which are harmful to people, this product has no health influence phone owners.

Sinowon macro Vision Measuring Machine with good price for small parts 5


Application


◆ Hardness testing of metals and scientific researching;

◆ Hardness range from soft materials to very hard materials;

◆ Except very thin and coated layers, can test almost the metals.



Characteristics


◆ Apply closed loop loading sensor, MPU controls the loading, dwell and unloading process;

◆ Equips with LCD screen, show loading force, hardness value, dwell time;

◆ Manually reading indentation, then input dialog length to calculate hardness value;

◆ Available to add optional mini printer, motorized turret, and VicPad measurement device or PC software iVicky 2.0.


Specification



Product NameVickers hardness tester
ModelV-5V-10V-30V-50
Code#821-101821-111821-121821-131
Loading ForceN2.94、4.9、9.8、19.6、24.5、29.4、49.02.94、4.9、9.8、19.6、24.5、29.4、49.0、98.04.9、9.8、19.6、24.5、29.4、49.0、98.0、196、2949.8、19.6、24.5、29.4、49.0、98.0、196、294、490
Kgf0.3、0.5、1、2、2.5、3、50.3、0.5、1、2、2.5、3、5、100.5、1、2、2.5、3、5、10、20、301、2、2.5、3、5、10、20、30、50
Optic SystemObserve and Measure Objectives:10X/20XObserve and Measure Objectives:10X/40XObserve and Measure Objectives:10X/20XObserve and Measure Objectives:10X/20X
Hardness Range1HV-2967HV
TurretManual Turret(Optional Motorized Turret)
Loading ControlAuto loading dwell and unloading
Eyepiece10x mechanical eyepiece
Dwell Time5-60s adjustable
IlluminationLED / halogen
Vertical Space170mm
Horizontal Space130m
Power SupplyAC220V/50Hz; AC110V/60Hz
Tester Dimension530x225x630mm
Packing Dimension630x460x710mm
Gross / Net Weight75Kg/55Kg
Conform StandardsISO6507,ASTM E92,JIS Z2244,GB/T4340
