Sinowon reliable brinell machine customized for measuring 1

Sinowon reliable brinell machine customized for measuring 2

Sinowon reliable brinell machine customized for measuring

Model:

Vexus MHV-1000Plus

Code#:

823-113Plus

Warranty:

12 month

Delivery Time:

15-30days

Standard:

JIS B -7735, ASTM E-384 and ISO 146

Certificate:

Inquiry

Sinowon reliable brinell machine customized for measuring 3

Characteristics

◆ Micro-Vickers hardness tester with button control panel;

◆ Strong and stable body;

◆ LED illumination, light, adjustable, long life and no heat;

◆ Data storage for review and printing;

◆ Rotatable turret with five working positions;

◆ 200 lines encode with precise measurement;

◆ D1 and D2 exchange automatically(Vexus MHV-2000);

◆ Two indenters available(Vickers and Knoop);

◆ Can be developed to semi-automatically or full-automatically system.

Application Range

◆ Testing very thin materials like foils, thin pieces, coatings layers, etc;

◆ Measuring hardness of the surface of a part, small parts or small areas;

◆ Measuring individual micro-structures;

◆ Measuring the depth of case hardening by sectioning a part and making a series of indentations to describe a profile of the change in hardness.

Specification

Model		Vexus MHV-1000Plus	Vexus MHV-2000Plus
Code#		823-113Plus	823-213Plus
Test Load	gf	10 / 25 / 50 / 100 / 200 / 300 / 500 / 1000 / 2000 (option)
	mN	98.07/ 245.2/ 490.3/ 980.7/ 1961/ 2942/ 4903/ 9807/19614 (option)
Loading Mechanism		Automatic loading and releasing method 50 ~100 µm/s
Dwell Time		5 ~ 99 s
Turret Mechanism		Automatic
Objective		40x/10x ( Option:20x,80x )
Magnification of Microscope		For measurement :400x ( Objective 40X and Eyepiece 10X )
		For observation : 100x ( Objective 10X and Eyepiece 10X )
Measuring Microscope		Electronic
Max. Measuring length		230 µm ( In case of 400x )
Mix. Measuring unit		0.1µm (0.01µm for TS type)
Max.Specimen Height		90mm
Max.Specimen Depth		110mm
Measuring Hardness Scale		HV, HK
X-Y Stage		Manual type
Dimensions		110 × 110 mm
Max. movement		25 × 25 mm
Min. micro graduation		1/100 mm
Light Source		LED Illuminator
Print Output		Measured data and statistic data :( Max. Value / Min. value / Mean value / Range / Standard deviation )
Accuracy		Conform to : JIS B -7735, ASTM E-384 and ISO 146
Photographic Device		Capable to mount photographic device ( Option)
Dimensions		W 190 × D 430 × H 520 mm
Weight		40Kg
Power Supply		Single phase AC 220 V 50/60 Hz

Software Introduction

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
