Sinowon Toolmakers Microscope inquire now for steel products1
Model:
STM-1050
Code#:
531-130
Accuracy:
≤5um
Warranty:
12 month
Delivery Time:
15-30days
Certificate:
CE
Company Advantages
1. Sinowon tool makers microscope wikipedia is developed as per the specifications laid by customers. A quality control system is implemented for the product
2. This product provides substantial savings in energy consumption and electricity bills. People can set assure to use it as often as they can. The product is analyzed and tested cautiously before packing
3. This product tends to have more superiorities in performance. The product is excellent in dust prevention
4. There is continuous attention to quality throughout the production process. Innovation is always made to update the product
![Sinowon Toolmakers Microscope inquire now for steel products1 8]()
![Sinowon Toolmakers Microscope inquire now for steel products1 9]()
![Sinowon Toolmakers Microscope inquire now for steel products1 10]()
![Sinowon Toolmakers Microscope inquire now for steel products1 11]()
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is one of the best toolmakers microscope producer. Sinowon Innovation Metrology Manufacture Limited. has a comprehensive professional production equipment and sophisticated production team.
2. Sinowon Innovation Metrology Manufacture Limited. has advanced research technology, professional management and strict quality control system.
3. There are many experienced managing talents and professional technician with strong ability of measuring microscope developing in Sinowon Innovation Metrology Manufacture Limited.. Sinowon Innovation Metrology Manufacture Limited. will lead the future of tool makers microscope wikipedia market. Get more info!
1. Sinowon tool makers microscope wikipedia is developed as per the specifications laid by customers. A quality control system is implemented for the product
2. This product provides substantial savings in energy consumption and electricity bills. People can set assure to use it as often as they can. The product is analyzed and tested cautiously before packing
3. This product tends to have more superiorities in performance. The product is excellent in dust prevention
4. There is continuous attention to quality throughout the production process. Innovation is always made to update the product
Application:
It is widely used in mechanical, meter, electronic and light industry; university, Institute and metrology department. The measuring profile projector can detect the contour dimension and surface shape of variety complex workpiece, such as templates, punching pieces, cams, threads, gears, molding milling cutters.
Product Feature
◆ Precision working stage travel:100 x50mm;
◆ High precision linear scale : 0.5um;
◆ Color screen multifunctional digital readout : DP400;
◆ Optical objective with adjustable LED ring reflector illumination;
◆ With high accuracy and high stability;
Specification
| Model | STM-1050 |
| Code# | 531-130 |
| Metall Stage Size | 252×252mm |
| Glass Stage Size | 196×96mm |
| Resolution | 0.5um |
| Measuring Accuracy | ≤5um |
| Measuring Device | Digital Readout DP400 |
| Max.Height of Specimen | 115mm |
| Max.Weight of Specimen | 5Kg |
| Max.Magnification | 150×（Φ0.13mm）（15×Eyepiece+10×Objective） |
| Min.Magnification | 20×（Φ6.5mm）（10×Eyepiece+2×Objective） |
| Standard Magnification | 30×（Φ0.13mm）（15×Eyepiece+2×Objective） |
| Standard Working Distance | 67mm |
| Optical Tube | Monocular with 30°depression angle |
| 15×Eyepiece with Crossline Reticle | |
| Eyepiece | WF15/13 |
| Objective | Magnification:2× |
| Working Distance:2.638"(67mm) | |
| Eyepiece Protractor Range | 360° |
| Eyepiece Protractor Graduation | 1° |
| Vernier Angle Reading | 6’ |
| Contour Illumination | Light source:Tungsten bulb(24V;2W) |
| Surface Illumination | Ring LED illumination brightness adjustable |
| Power Supply | AC110V/60Hz;220V/50Hz |
| Dimension(D×W×H) | 415×315×420mm |
| Packing Dimension(D×W×H) | 210×333×391mm |
| Gross/Net Weight | 30Kg/25Kg |
Standard Delivery:
| Accessory Name | Code# | Accessory Name | Code# | Accessory Name | Code# |
| 15XEyepiece | 531-522 | 2X Objective | 531-602 | Ring Illumination | 413-146 |
| Linear Scale | 581-201 | Power Cable | 581-921 | Operation Manual | STM-1050 |
