Sinowon Video measurement system with good price for small areas

Model:
Vicky TV-10A
Code#:
821-240
Warranty:
12 month
Delivery Time:
15-30days
Standard:
ISO6507,ASTM E92,JIS Z2244,GB/T4340
Certificate:
CE
Inquiry
Company Advantages
1. Quality test for Sinowon vickers hardness testing machine will be carried through. Important tests for its solar modules such as exposing the cells to heat and cold conditions to check its performance. The product is CE certified for the European market
2. It is popular with a variety of customers in the industry. Innovation is always made to update the product
3. Every product undergoes a strict control process to ensure the best quality. The Gost certificate has been obtained for the Russian market
4. Under the supervision of a professional quality inspector, the product is inspected at all stages of production to ensure good quality. Imported materials and accessories are used in product manufacturing

Sinowon Video measurement system with good price for small areas 3


Application


◆ Hardness testing of metals and scientific researching;

◆ Hardness range from soft materials to very hard materials;

◆ Except very thin and coated layers, can test almost the metals.



Characteristics


◆ Equips with Auto Turret, close loop loading system, key panel and touch screen double input methods, blue tooth transferring technology, meets different kinds of materials measuring requirement.

◆ Close loop loading system is to realize auto loading, dwell and unloading, makes better accuracy and easier installation.

◆ 5.2” color touch screen with innovative interface design, makes force selection, dwell time setting, scale conversion and data reading, transferring, printing more convenient and fast.

◆ Operator can smoothly switch objectives and indenter by auto turret, maximally avoid damages of objectives, indenter and force system by manually operation.

◆ One touch operation of diagonal line by high resolution measurement/observation objectives and built-in length encoder high definition digital eyepiece.

◆ Auto hardness conversion from vickers scale HV to HK, HBW, HRA, HRB, HRC, superficial rockwell scales, etc.

◆ Equips with Bluetooth Device, optional Bluetooth printer and computer acceptor is available to realize wireless printing and data transferring.

◆ Abundant optional auxiliary devices to make hardness measurement more automated and eliminate human operation error, VicPad Vickers measurement device and iVicky 2.0 PC software system.


Specification



Product NameTouch Screen Digital Vickers Hardness Tester
ModelVicky TV-5AVicky TV-10AVicky TV-30AVicky TV-50A
Code#821-220821-240821-260821-280
Loading ForceN2.94、4.9、9.8、19.6、24.5、29.4、49.02.94、4.9、9.8、19.6、24.5、29.4、49.0、98.04.9、9.8、19.6、24.5、29.4、49.0、98.0、196、2949.8、19.6、24.5、29.4、49.0、98.0、196、294、490
Kgf0.3、0.5、1、2、2.5、3、50.3、0.5、1、2、2.5、3、5、100.5、1、2、2.5、3、5、10、20、301、2、2.5、3、5、10、20、30、50
Optic SystemObserve and Measure Objectives:10X/20XObserve and Measure Objectives:10X/40XObserve and Measure Objectives:10X/20XObserve and Measure Objectives:10X/20X
Hardness Range1HV-2967HV
TurretManual Turret(Optional Motorized Turret)
Loading ControlAuto loading dwell and unloading
Eyepiece10x digital Eyepiece
Dwell Time5-60s adjustable
IlluminationLED / halogen
Vertical Space170mm
Horizontal Space130m
Power SupplyAC220V/50Hz; AC110V/60Hz
Tester Dimension530x225x630mm
Packing Dimension630x460x710mm
Gross / Net Weight75Kg/55Kg
Conform StandardsISO6507,ASTM E92,JIS Z2244,GB/T4340
