automatic micro vickers hardness tester series for small parts

Company Advantages
1. A range of quality inspections for Sinowon microindentation hardness testing will be carried out by professionals. It will be checked in terms of surface smoothness, stability, harmoniousness with space, and actual practicability.
2. The product is free of burrs on its surface. The adopted mold structure is reasonable to refuse any burrs during production.
3. This product is eco-friendly and harmless. The painting or pigment used in it are guaranteed to meet the environmental protection standards of European and American.
4. Any feasible suggestions for Sinowon Innovation Metrology Manufacture Limited. will be warmly welcomed and we will also seriously consider them.

◆ It adopts die-cast body, stability is much higher than in the mechanical performance of sheet metal welding machines;

◆ It is equipped with 10X and 40X HD lens and HD USB camera, the instrument measured images in optical imaging system and video of great quality;

◆ Combined with MV-1000 video measuring devices, It improves efficiency, reduces visual fatigue of the operator.

◆ Testing very thin materials like foils, thin pieces, coatings layers, etc;

◆ Measuring hardness of the surface of a part, small parts or small areas;

◆ Measuring individual micro-structures;

◆ Measuring the depth of case hardening by sectioning a part and making a series of indentations to describe a profile of the change in hardness.

Product Name		Micro Hardness Tester with Measurement Monitor
Model		MV-1000V
Code#		823-101V
Loading force	N	0.098、0.246、0.49、0.98、1.96、2.94、4.90、9.80
	Kgf	10、25、50、100、200、300、500、1000
Indentation Measuring Device		MV-100
Switch of Objectives and Pressure Switch		Auto-turret
Loading Control		Auto Loading, Dwell and Unloading
Magnification of Objective		Observation：10x/40x；Measurement：10x/40x
Video System		CMOS Measuring Eyepiece, 8 "Display
Dwell Time		5-60s
Measuring Range		1HV-2967HV
X-Y Anvil		Size：100X100mm；  Travel：25mm X 25mm;Resolution：2um
Maximum Height and Width of Specimen		Maximum Height：70mm; Maximum Width：95mm
Power supply		AC220/50Hz; AC110V/60Hz
Dimension		425X245X490mm
Gross/Net Weight		45kg/35Kg
Executive Standard		GB/T4340.2, EN-ISO6507,ASTME10-08,ASTME-384

Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is gradually taking the leading trend in the trade of micro vickers hardness tester .
2. The Sinowon's commitment to hardness testing machine quality improvement and new product development is unwavering.
3. Sinowon will persistently provide superior vickers microhardness. Please contact us! Sinowon Innovation Metrology Manufacture Limited. intends to be the best manufacturer of vicker hardness tester in the global market. Please contact us!
