Automatic Precision Cutter AC-250 Series

Company Advantages
1. Typical parameters of Sinowon grinding and polishing equipment being measured include flexure, tension, compression, peel strength, adhesive/bond strength, puncture, insertion/extraction and sliding of pistons. More than 10,000 pcs have been delivered and installed
2. This product is widely used by people from all walks of life. The product is excellent in dust prevention
3. The product is quality certified for long life. It is supported by multiple languages say English, Turkish, and German
4. In order to meet the international quality standards, this product has passed strict quality inspection procedures. The product can be controlled in a motorized way, to eliminate errors caused by manual operation
5. The products have passed strict quality examination and inspection before they leave the factory. A quality control system is implemented for the product

◆ Powerful motor to reduce cutting time and provide high productivity

◆ Smart feed. The machine can adjust the feed speed in real time with the load changes

◆ Cutting modes: Y-continuous, Y-pulse, Z-continuous, Z-pulse, slicing (different model, different cutting mode)

◆ Versatile industrial joystick with X, Y, Z axis. Easy to use

◆ 8 inch color touchscreen for simple operation and user friendliness

◆ Electrical brake for faster stopping of the blade

◆ Chamber illumination with LED

◆ Aluminum casting base, powder coated

◆ T-slot Table made of stainless and aluminum alloy

◆ Fast Cam Locking Vises, made of 304 stainless steel

◆ Left cover made of composites by integral molding

◆ Mobile plastic recirculation coolant tank

◆ Independent pump for cleaning the chamber

◆ Optional laser alignment aid

Description	AC-250XYZ	AC-250YZ	AC-250Z
Y Feed	Automatic
Z Feed	Automatic	Automatic	---
X Feed	Automatic	○Manual	○Automatic○Manual
Cutting mode	Continuous, Pulse	Continuous, Pulse	Continuous, Pulse
Blade(mm)	250*32*1.5
Blade speed (rpm)	500-3000
Table Dimensions (WxD,mm)	279*260
X Travel	60mm
Cooling	Automatic/manual
Main Motor	2.2KW
Power	110/220V AC, 50-60Hz,   1 Phase
Accessories
Diamond Blade	○	○	○
SiC blade	○	○	○
Alumina Blade	●	●	●
Fast Cam Locking Vises	●	●	●
Vertical Clamping vise	○	○	○
Laser alignment aid	○	○	○
Plastic tank	●	●	●
Plastic tank with magnetic filter	○	○	○
Cutting fluid	○	○	○
Centrifugal separator	○	○	○
Base Bench	○	○	○

●standard○option
