Custom video measuring linear scale Sinowon configuration

Company Advantages
1. A quality control system is implemented for the product. We have many years of experience in digital linear measuring scale market and have a good reputation in this field.
2. All Sinowon linear scale are sold with a digital linear measuring devices-day risk-free performance guarantee to ensure complete customer satisfaction. A team of experienced talents is gathered to support the product sales.
3. It is easy to operate, with fast speed, We Believes That Our Factory Is The Best Place For Your vision software, vision system software, vision accessories Oem Orders.
4. Sinowon machine vision software are manufactured to a higher quick vision software and greater vision control software than visionscape software for more demanding applications. The product is highly praised in many exhibitions such as Shanghai Electronica China Show.



EFFICIENT

◆Compact design

◆Low weight

◆Low energy consumption

VERSATILE

◆Distance and thickness

◆Works on all surfaces/materials

◆Interchangeable probes

USER-FRIENDLY AND SAFE

◆Maintenance-free

◆Simple to integrate

◆Non-contact

Application	Distance,   thickness
Measurements /second	up   to 4000
Synchronization   with external devices	Trigger   input, synchronizing output
Interface	Ethernet,   RS-422, RS-232, external analogue converter box as accessory
Transfer   Rate	Ethernet   (100 Mbit); RS-422, RS-232 (9600 - 1843200 Baud)
Light   Source	LED
Protection   Class	IP50
Operating   Temperature	0°C   to + 50°C
Storage   Temperature	-20°C   to 70°C
Dimension   (l x w x h)	99   mm x 65 mm x 47 mm (without probe)
Weight   (without probe)	430   g
Supply   Voltage	24   V
Rated   Power	4   W
SDK	DLL   written in C, C++; SDK written in C# with .NET framework 4
Order   Number	5009276
Accessories	Extension   box for synchronization with external devices(order number 5009932)

Model	Probe   200μm	Probe   1 mm	Probe   4 mm	Probe   10 mm
Measuring   Range	200   μm	1   mm	4   mm	10   mm
Working   Distance1) (mm)	4.7   +/- 0.3	15.7   +/- 0.5	36.7   +/- 0.7	68.7   +/- 1
Spot   Diameter	3.4   μm	5   μm	8   μm	16   μm
Lateral   Resolution	1.7   μm	2.5   μm	4   μm	8   μm
Axial   Resolution	8   nm	40   nm	160   nm	400   nm
Linearity2)	150   nm	400   nm	1.6   μm	4   μm
Measurement   angle to surface3)	90°   +/- 45°	90°   +/- 28°	90°   +/- 20°	90°   +/- 14°
Thickness   Measuring Range4)	up   to 0.3 mm	up   to 1.5 mm	up   to 6 mm	up   to 15 mm
Weight	41   g	31   g	57   g	86   g
Dimensions   (outside) (mm)	d   = 28, l = 23.7	d   = 28, l = 17	d   = 34, l = 26.6	d   = 40, l = 35.3
Order   Number	5009278	5009279	5009280	5009281

¹⁾ Bottom of optical probe to middle of measuring range

²⁾ Perpendicular measurement on mirror at 20° C

³⁾ Decreasing linearity on the limits

⁴⁾ Refractive index n = 1.5

Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is fully capable of manufacturing premium linear scale. Sinowon Innovation Metrology Manufacture Limited. has advanced automatic machines and inspected equipment for vision software production.
2. Sinowon seriously introduces the production of high-tech machines machine vision software.
3. With advanced technologies competitiveness, Sinowon Innovation Metrology Manufacture Limited. occupies a wide overseas market of color video camera. We pledge to exceed your expectations in every aspect of service and performance. Get info!
