A professional manufacturer of measuring & testing equipment.

digital microscope review video for soft alloys Sinowon 1
digital microscope review video for soft alloys Sinowon 2
digital microscope review video for soft alloys Sinowon 3
digital microscope review video for soft alloys Sinowon 4
digital microscope review video for soft alloys Sinowon 5
digital microscope review video for soft alloys Sinowon 6
digital microscope review video for soft alloys Sinowon 1
digital microscope review video for soft alloys Sinowon 2
digital microscope review video for soft alloys Sinowon 3
digital microscope review video for soft alloys Sinowon 4
digital microscope review video for soft alloys Sinowon 5
digital microscope review video for soft alloys Sinowon 6

digital microscope review video for soft alloys Sinowon

Model:
VM-500
Code#:
451-450
Warranty:
12 month
Delivery Time:
15-30days
Certificate:
CE
Inquiry
Enterprise Strength
  • Sinowon not only produces high-quality products but also provide professional after-sales services.
Company Advantages
1. Conforming to the design standard, Sinowon video microscope system has an appealing appearance.
2. The product is nonporous. It is processed under a high firing temperature which can eliminate all water bubble and air.
3. Whether the motivations are economic, environmental, or personal, the benefits of this product will have something to offer for everyone.


digital microscope review video for soft alloys Sinowon 7

Application:
Incoming inspection, production inspection, material research, PCB and SMT inspection analysis, printing, textile inspection, biological anatomy, medical testing and other fields.


Product Feature


Integral design, exquisite, fashion, generous;

Built-in FULL HD sensor and VGA integrated camera, can directly connect with the monitor to realize video image and can also use SD card to take picture or record video, which integrate video observation and image storage;

With high definition 0.7~4.5X parallel continue zoom lens, it is more convenient and fast to switch objective magnification;

With adjustable LED surface reflection illumination, is able to control brightness independently;

With 2 million pixel auto focus camera, no need to waste time for manual focus frequently.


Specification



Product NameAuto Focus Video Microscope
ModelVM-500
Code#451-450
Electronic Magnification32X~206X( VGA 4:3 21”Monitor;)
Optical Objective0.7X~4.5X Horizontal Zoom Lens
Zoom ratio:6.5:1
0.5X C-mount Camera Adapter
Camera Parameters2 million pixel (1920*1080)
Image Size:1/2.86”
Frames Per Second:30fps
Camera FunctionAuto Focus
Cross Line
Photograph and Video Record
Output: HDMI
White Balance; Brightness Control; Digital Noise Reduction
IlluminationSurface: Adjustable LED Surface Illumination
Ring Fiber Illumination Optional
Microscope StandZ-axis Travel: 100mm
Coarse Lifting System
Electrical ParametersAC90~240V;50~60HZ
Dimension310*285*500 mm
Weight6Kg


Accessories:


Product NameSpecification
Microscope Main BodyVM-500
Power AdapterDC5V(Camera)、DC12V(Illumination)
MonitorOptional 4:3 21.5”
Operation Manual/Warranty Card/Certificate/Packing listVM-500


Field of View:


Auxiliary
objective
Field of view (0.5X Camera Adapter)
0.7X1X2X3X4X4.5XRemark
LengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonal
0.5X
WD:108mm
Magnification 0.18X-1.12XOptional
25.2922.8634.0917.7016.0023.868.858.0011.935.905.337.954.434.005.973.933.565.30
1.0X
WD:91mm
Magnification 0.35X-2.25XStandard
12.6411.4317.048.858.0011.934.434.005.972.952.673.982.212.002.981.971.782.65
2.0X
WD:35.3mm
Magnification0.70X-4.50XOptional
6.325.718.524.434.005.972.2122.981.481.331.991.111.001.490.980.891.33


Product Details



digital microscope review video for soft alloys Sinowon 8
digital microscope review video for soft alloys Sinowon 9
digital microscope review video for soft alloys Sinowon 10
digital microscope review video for soft alloys Sinowon 11




Company Features
1. In the course of several years'development, Sinowon Innovation Metrology Manufacture Limited. has developed into an influential company specializing in the manufacturing of video microscope system .
2. The improvement of technical force also facilitates the development of Sinowon.
3. We use risk assessments at our suppliers and during the product development process to make sure we live up to our consumer’s expectations as well as all regulatory requirements. Better quality and service is our goal. Check now! We consider that we have the responsibility to protect our environment. During our production processes, we consciously minimize our impact on the environment. For example, we have introduced special wastewater treating facilities to prevent polluted water from flowing into seas or rivers.
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
