Educational Miniature Machining Lathe Telathe300A

Product Applications

Telathe300A Miniature Lathe: Designed for educational purposes, hobby collections, and practical machining applications.



Product Introduction

  • Every component undergoes strict quality control in material selection, hardness testing, machining, and surface treatment. Detailed data reports are archived to ensure traceability and compliance with international standards.
  • The entire machine is crafted from aluminum alloy and finished with CNC precision machining for enhanced metallic aesthetics.

Telathe300A Miniature Lathe Advantages

  • Compact size, high precision, user-friendly operation, and portability.
  • Capable of machining diverse materials: copper, aluminum, plastic, wood, etc.
  • Key Features: External/internal diameter turning, live center support for external turning, drilling, polishing, concentricity testing, and more.
  • Machining Accuracy: Roundness accuracy: 0.003–0.004mm; external diameter accuracy: ±0.005mm; surface roughness: Ra0.8 (dependent on operator skill).



Product Features

  • Color Options: Raw machined finish, bright silver, and luxury gold—each exudes a premium texture to suit varied aesthetic preferences.
  • Power Supply: 220V household voltage with a 24V 5A adapter for flexible usage.
  • Clamping Range: Forward/reverse jaws accommodate diameters from 1.0–50.0mm, catering to most user needs.
  • Max Machining Length: External diameter processing up to 95mm for small workpieces.
  • Spindle Speed: Brushless motor with 0–3000rpm stepless speed control ensures stable performance.



Technical Specifications

Model (mm)

H

L1

L2

X Travel

Z Travel

Net Weight(kg)

Remarks

Telathe300A

150

400

215

50

70

6.4

Educational Type



Product Structure Diagram
