A professional manufacturer of measuring & testing equipment.

excellent portable vickers hardness tester inquire now for measuring 1
excellent portable vickers hardness tester inquire now for measuring 2
excellent portable vickers hardness tester inquire now for measuring 1
excellent portable vickers hardness tester inquire now for measuring 2

excellent portable vickers hardness tester inquire now for measuring

Model:
SV-30
Code#:
821-121S
Warranty:
12 month
Delivery Time:
15-30days
Standard:
ISO6507,ASTM E92,JIS Z2244,GB/T4340
Certificate:
CE
Inquiry
Product Details
Sinowon's optical measurement instruments is processed based on advanced technology. It has excellent performances in the following details.Sinowon's optical measurement instruments is commonly praised in the market due to good materials, fine workmanship, reliable quality, and favorable price.
  • excellent portable vickers hardness tester inquire now for measuring 3
Application Scope
Sinowon's hardness testing machines can be used in many industries.With a focus on vision measuring machine, Sinowon is dedicated to providing reasonable solutions for customers.
  • excellent portable vickers hardness tester inquire now for measuring 4
Company Advantages
1. The production process of Sinowon portable vickers hardness tester is streamlined, minimizing the waste.
2. The product has been internationally approved in terms of performance and quality.
3. This product is highly recognized by customers for its durability and long-lasting performance.
4. The product can be erected on any surface and doesn’t require the preparation of footings needed for permanent structures.

excellent portable vickers hardness tester inquire now for measuring 5


Application


◆ Hardness testing of metals and scientific researching;

◆ Hardness range from soft materials to very hard materials;

◆ Except very thin and coated layers, can test almost the metals.



Characteristics


◆ Apply closed loop loading sensor, MPU controls the loading, dwell and unloading process;

◆ Equips with LCD screen, show loading force, hardness value, dwell time;

◆ Just aim the dialog line, then it will automatically reading the length and display hardness value

◆ Available to add optional mini printer, motorized turret, and VicPad measurement device or PC software iVicky 2.0.



Specification



Product NameDigital Vickers hardness tester
ModelSV-5SV-10SV-30SV-50
Code#821-101S821-111S821-121S821-131S
Loading ForceN2.94、4.9、9.8、19.6、24.5、29.4、49.02.94、4.9、9.8、19.6、24.5、29.4、49.0、98.04.9、9.8、19.6、24.5、29.4、49.0、98.0、196、2949.8、19.6、24.5、29.4、49.0、98.0、196、294、490
Kgf0.3、0.5、1、2、2.5、3、50.3、0.5、1、2、2.5、3、5、100.5、1、2、2.5、3、5、10、20、301、2、2.5、3、5、10、20、30、50
Optic SystemObserve and Measure Objectives:10X/20XObserve and Measure Objectives:10X/40XObserve and Measure Objectives:10X/20XObserve and Measure Objectives:10X/20X
Hardness Range1HV-2967HV
TurretManual Turret(Optional Motorized Turret)
Loading ControlAuto loading dwell and unloading
Eyepiece10x digital Eyepiece
Dwell Time5-60s adjustable
IlluminationLED / halogen
Vertical Space170mm
Horizontal Space130m
Power SupplyAC220V/50Hz; AC110V/60Hz
Tester Dimension530x225x630mm
Packing Dimension630x460x710mm
Gross / Net Weight75Kg/55Kg
Conform StandardsISO6507,ASTM E92,JIS Z2244,GB/T4340






Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is a renowned company which integrates manufacturing, processing, dyeing and selling of Video measurement system.
2. With a strong sense of responsibility, our professional technicians pay attention to each detail of the Vision Measuring Machine to guarantee the quality.
3. Sinowon firmly believes that high quality and professional service will finally pay off. Check now! By constant innovation, Sinowon Innovation Metrology Manufacture Limited. aims to take the lead in the field of Video measurement system. Check now!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
