hot selling brinell hardness test procedure series for steel products
1. Sinowon the brinell hardness test must be inspected in many aspects. They are harmful substances content, lead content, dimensional stability, static loading, colors, and texture. The product is analyzed and tested cautiously before packing
2. People who bought this product said that it has helped solve the problem of energy loss and give the savings back in terms of overall energy efficiency. Its packing is made seriously to guarantee the safety during shipment
3. The product is given superior quality that surpasses the industrial standard. A quality control system is implemented for the product
4. The performance of this product is assured by your QC team. The product is highly praised in many exhibitions such as Shanghai Electronica China Show
Product Feature
◆ AutoBrin-3000A is the latest generation digital Brinell hardness tester, it equips with motorized turret to install 10mm, 5mm, 2.5mm tungsten carbide ball indenter, 1x and 2x objectives simultaneously, avoid operation error during switch indenter and objectives.
◆ Apply large LCD to display testing parameters and results, indentation can be measured by 10x digital eyepiece, also available to realize hardness conversion among 17 hardness scales.
◆ Loading control by load cell with accuracy at 0.5‰, microchip can make force compensation automatically lost during loading.
◆ Indentation measurement system integrated by 10x digital eyepiece, 1x and 2x objectives, eliminates manually brinell table checking, to realize directly indentation measurement and display hardness result on LCD.
◆ AutoBrin-3000A equips with built-in mini printer, and can transfer data to computer by RS232, to do further analysis by PC software.
◆ Optional accessory for AutoBrin-3000A has Brinell Optical Measuring System BrinScan.
Application
Because of brinell method apply big loading force and generate big indentation, it is suitable to test hardness of coarse-grained metals, like cast iron, non ferrous metal and their alloy, sale of steels, etc.
Soft metals are also available to test, like Aluminium, copper, plumbum, tin, zinc and their alloy, etc.
Specification
| Name | Auto Turret Digital Brinell Hardness Tester | |
| Model | AutoBrin-3000A | |
| Code# | 831-151 | |
| Loading Force | Kgf | 62.5Kgf, 100Kgf, 125Kgf, 187.5Kgf, 250Kgf, 500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf |
| N | 612.9N, 980N, 1226N, 1839N, 2452N, 4900N, 7355N, 9800N, 14700N, 29400N | |
| Hardness Resolution | 0.1HBW | |
| Brinell Range | (8-650) HBW | |
| Hardness Reading | Display on LCD | |
| Indentation Measurement | Magnification 10x/20x, eyepiece 10x and objective 1x, 2x | |
| Data Output | Mini printer/RS232 | |
| Vertical Space | 260mm | |
| Horizontal Space | 150mm | |
| Dimension | 890×535×260mm | |
| Gross/Net Weight | 180Kg/150Kg | |
| Power Supply | AC 220V/110V±5%，50~60 Hz | |
| Conform Standard | GB/T231.2, JJG150, EN-ISO 6506； ASTM E10-12; JIS Z2243 | |
Accuracy | ||
| Hardness Range | Permitted Error | Repeatability |
| HBW≤ 125 | ≤± 3.5％ | ≤ 3.5％ |
| 125＜HBW≤225 | ≤± 2.5％ | ≤ 3.0％ |
| HBW＞ 225 | ≤± 2.0％ | ≤ 2.5％ |
Company Features
1. As a strong and influential company, Sinowon Innovation Metrology Manufacture Limited. has been widely recognized in the field of brinell hardness test procedure . Sinowon Innovation Metrology Manufacture Limited. is known for its strong research and solid technical foundation.
2. Sinowon Innovation Metrology Manufacture Limited. is solid and powerful according to its technical foundation.
3. There's a strict and complete quality management system to guarantee the quality of brinell hardness . We keep a watchful eye on the environmental impact we caused. To achieve sustainable development, we strive hard to reduce energy waste and pollution during the production processes.
