A professional manufacturer of measuring & testing equipment.

hot selling brinell hardness unit customized for cast iron 1
hot selling brinell hardness unit customized for cast iron 2
hot selling brinell hardness unit customized for cast iron 1
hot selling brinell hardness unit customized for cast iron 2

hot selling brinell hardness unit customized for cast iron

Model:
SHB-3000E
Code#:
831-111
Accuracy:
≤±3.5%
Warranty:
12 month
Delivery Time:
15-30days
Standard:
ISO 6506,ASTM E10 – 12,JIS Z2243,GB/T 231
Certificate:
CE
Inquiry
Company Advantages
1. Sinowon brinell indenter goes through a series of sophisticated treatment to ensure its high quality. For example, the heat-treated process is conducted to eliminate any toxic elements. It has been marketed successfully for 12 years, thanks to the excellence in quality and technology
2. The product is more competitive in the commercial market and has a broad market prospect. The product is highly praised in many exhibitions such as Shanghai Electronica China Show
3. The product can resist excessive humidity. It is not susceptible to the huge moisture that could result in the loosening and weakening of joints and even failure. Imported materials and accessories are used in product manufacturing
4. People with symptoms such as allergies and eczema can usually be relieved from the symptoms by using this product. The product is excellent in dust prevention
5. This product is not easily pilling or damaged by severe wear. Its textile fibers are treated with an antistatic agent to reduce static electricity and reduce wear between the fibers. The quality is reliable and the service life is long

hot selling brinell hardness unit customized for cast iron 3



Product Feature


 SHB-3000E adopts the load cell to replace the traditional weight, this innovative design makes the instrument more accurate;

 SHB-3000E selection of testing force and dwell time is controlled and monitored on the front panel, it is automatic during the process of loading, dwell and unloading;

 SHB-3000E uses 20x Brinell measuring microscope to measure the diameter of indentation, then the operator traces the Brinell hardness table to get the testing result.



Specification



Name

Electronic Brinell Hardness Tester

Model

SHB-3000E

Code#

861-111

Loading ForceKgf

62.5Kgf, 100Kgf, 125Kgf, 187.5Kgf, 250Kgf,  500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf

N

612.9N, 980N, 1226N, 1839N, 2452N, 4900N, 7355N, 9800N, 14700N, 29400N

Brinell Range(8-450) HBS,(8-650) HBW
Hardness DisplayCheck the Table of Brinell Hardness Scale
Magnification of Microscope

Analogue 20x Microscope

Vertical Space

225mm

Horizontal Space

135mm

Dimension

893 x720 x747mm

Gross/Net Weight

160Kg/130Kg

Power Supply

AC220V/50Hz;110V/60Hz

Conform Standard

ISO 6506,ASTM E10 – 12,JIS Z2243,GB/T 231

Accuracy

Hardness RangePermitted ErrorRepeatability
HBW≤ 125≤± 3.5%≤ 3.5%
125<HBW≤225≤± 2.5%≤ 3.0%
HBW> 225≤± 2.0%≤ 2.5%





Company Features
1. The reliability of Sinowon has been greatly improving in customers' view. Over the years, we have built up a strong customer base that is loyal to us for years. The long-term cooperation with those customers promotes to achieve a win-win situation.
2. We have recently invested in testing facilities. This allows the R&D and QC teams in the factory to test new developments in market conditions and to simulate long-term testing of the products prior to launch.
3. Our company has many product experts. They can meet product requirements in a short amount of time due to their experience and expertise in this field. Sinowon is growing rapidly complying with the tenet of brinell hardness unit . Please contact.
