Sinowon analog best computer vision software design for industry

Company Advantages
1. Sinowon computer vision models price features scientific structure and aesthetic appearance. It is well-designed by our dedicated designers who are equipped with innovative design ideas. It is well recognized by more than 5000 customers
2. The introduction of highly advanced machines promotes the bulk production of best computer vision software . The quality is reliable and the service life is long
3. The product is strongly resistant to rust. The materials of the frame adopt reinforced aluminum alloy whose surface has been treated with anodized finish. Innovation is always made to update the product



EFFICIENT

◆Precise

◆Rapid

◆Non-contact

VERSATILE

◆Distance and topography

◆Wide thickness measuring range

◆Measurements on all surfaces

◆Inline and offline

User Friendly

◆Maintenance-free

◆Simple to integrate

◆Nondestructive measurement

◆Robust

◆Automatic light control

Application	Distance,   thickness
Measurements /second	32   - 2000
Interferometric   Measuring Range 1)	3   μm - 180 μm
Chromatic   Measuring Range	Depends   on optical probe
Pitch   Error 2)	<   10 -3
Linearity   Error 2)	<   3.3 x 10 -4 x upper measuring range limit
Resolution	10   -7 x upper measuring range limit
Reproducibility	9   x 10 -5 x upper measuring range limit
Number   of measuring channels	1
Synchronization   with external devices	Trigger   input, synchronizing output, 3 encoder inputs
Interface	USB,   RS-232, RS-422, 2 x analog (0 V to 10 V, 16 Bit), LVDT 3)
Transfer   Rate	RS-232   (9600 - 921600 Baud); RS-422 (9600 - 921600 Baud); USB:   virtual comport (921600 Baud)
Light   Source	LED
Length   Optical Fiber4)	2   m - 40 m (multi mode fiber)
Fiber   Connection	E   2000
Operating   Temperature	+5°C   up to +50°C
Dimension   (w x h x d)	200   mm x 100 mm x 93 mm
Weight	1.1   kg
Supply   Voltage	16   - 30 V DC (with separate power supply 90 - 264 V AC)
Rated   Power	10   W

¹⁾ Optical length

²⁾ Measuring accuracy = linearity error + (pitch error x measuring value)

³⁾ Optional

⁴⁾ Metal cover up to 15 m also available

Company Features
1. Sinowon is responsible for best computer vision software business, and is the leading provider computer vision models price .
2. So far, we have won trust from customers around the world. We have been cooperating with them for years, and our workflows are smooth because we always know exactly customers' demands.
3. We are protecting resources and ecosystems. We're improving the quality of discharge, reducing CO2 emissions, and conserving water resources.
