A professional manufacturer of measuring & testing equipment.

Sinowon brinell hardness to rockwell series for nonferrous metals 1
Sinowon brinell hardness to rockwell series for nonferrous metals 2
Sinowon brinell hardness to rockwell series for nonferrous metals 1
Sinowon brinell hardness to rockwell series for nonferrous metals 2

Sinowon brinell hardness to rockwell series for nonferrous metals

Model:
Vexus SHB-3000D
Code#:
831-120
Accuracy:
≤± 3.5%
Warranty:
12 month
Delivery Time:
15-30days
Standard:
GB/T4340、JIS Z2245、ASTM—E92、ISO6507
Certificate:
CE
Inquiry
Application Scope
optical measurement instruments, one of Sinowon's main products, is deeply favored by customers. With wide application, it can be applied to different industries and fields.Sinowon is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
  • Sinowon brinell hardness to rockwell series for nonferrous metals 3
Company Advantages
1. The design of Sinowon digital brinell hardness tester is completed by our thoughtful designers who keep the health&safety standards and environmental protection concepts in mind.
2. This product has electromagnetic compatibility. It has a sufficient level of intrinsic immunity to electromagnetic disturbance to operate as intended.
3. This product is very safe. It is made of healthy materials which are non-toxic, VOCs-free, and odor-free.
4. People can be free of the worry that it will leave any chemical residues on their skin which may cause skin allergy.

Sinowon brinell hardness to rockwell series for nonferrous metals 4



Product Feature


 Vexus SHB-3000D differs from like products is the close loop loading system, key panel and touch screen double input methods, blue tooth transferring technology and digital measurement indentation technology;

 High accuracy close loop loading sensor replace traditional weights loading method, to realize automatic loading, dewell and unloading, makes easier installation and better measurement accuracy;

 Equips with 5.2” color touch screen with innovative interface design, makes force selection, dwell time setting, scale conversion and data reading, transferring, printing more convenient and fast;

 One touch operation of indentationmeasurement by high resolution objective, largely eliminate human error and avoid annoyance to check indentation comparison table;

 Auto hardness conversion from Brinell scale HBW to HK, HV, HRA, HRB, HRC, superficial rockwell scales, etc;

 Equips with Bluetooth Device, optional Bluetooth printer and computer acceptor is available to realize wireless printing and data transferring.

Specification



Name

Color Touch Screen Digital Brinell Hardness Tester

Model

Vexus SHB-3000D

Code#

831-120

Loading ForceKgf

62.5Kgf, 100Kgf, 125Kgf, 187.5Kgf, 250Kgf,  500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf

N

612.9N, 980N, 1226N, 1839N, 2452N, 4900N, 7355N, 9800N, 14700N, 29400N

Data TransferBluetooth;RS232 is optional
Brinell Range

(8-650) HBW

Hardness DisplayLCD Display
Languages

Chinese, English, German, Portuguese, Turkish,  Czech, Korean

Magnification of Eyepiece

20x Mechanic Microscope

Conversion Standard

ASTM、DIN

Vertical Space

225mm

Horizontal Space

135mm

Dimension

545 x235 x755mm

Gross/Net Weight

160Kg/130Kg

Power Supply

AC220V/50Hz;110V/60Hz

Conform Standard

GB/T4340、JIS Z2245、ASTM—E92、ISO6507

Accuracy

Hardness RangePermitted ErrorRepeatability
HBW≤ 125≤± 3.5%≤ 3.5%
125<HBW≤225≤± 2.5%≤ 3.0%
HBW> 225≤± 2.0%≤ 2.5%





Company Features
1. As a top producer for brinell hardness to rockwell , Sinowon Innovation Metrology Manufacture Limited. is extremely active in this field.
2. By keeping innovating the brinell hardness test technology, we can stay ahead in the industry.
3. We always adhere to the customer-oriented concept. By using advanced production technologies and mastering the market trends, we are confident to offer customers the best product solutions. We are devoted to playing an active role in protecting the environment. We sincerely cooperate with the environmental organizations or groups to partake in activities such as lowing carbon footprint during production and minimizing energy consumption.
