Sinowon digital readout supplier for soft alloys
1. Sinowon electronic linear scale is produced strictly complying with the domestic water purifier standards. It has passed the quality test which requires the water treated by this product are safe and clean.
2. Our presented product has a longer service life and durability.
3. This product is able to reduce neither the amount nor the weight of stuff that people bring with. It is a great helper.
4. Customers say the product is easy to clean and needs little maintenance, which means the operation cost of the product is relatively low.
Product Feature
◆ 5.6〃Color Screen and Sealed silicone touch button,with full information, friendly operation, long using life;
◆ Save 100 permanent image elements, can set and save current date;
◆ Multi-function Measurement: Point, line, circle,angle, distance, rectangular, screw thread, ellipse, slot, rounding, preset,construction, and so on;
◆ Obverse or Opposite direction counting function,1/2 value, midpoint, permission function, Call function, REC(record)function,and Cycle measurement;
◆ Section and linear compensation are available for 3-axis, highly ensure measurement accuracy:
◆ Can connect foot switch,printer, optical edge detection and other multiple auxiliary measurement tools;
◆ With polar and coordinate system, and can display millimeter and inch, and can shift easily;
◆ With independent password permission function, to prevent the posibility of data deviation by wrong operation, it can also change the original setting by password permission;
◆ Support multiple language:Chinese, English and other language;
Technical Specification
| Model | DP400(#510-340) |
| Language | Simple Chinese, Complicated Chinese, Portuguese, German and English, etc. |
| LCD Screen Size | 115mm×85mm |
| LCD Screen Resolution | 640*480 |
| Digital Display Range | 8Digits(With Decimal Point) |
| Display Axis | 3-axis (X,Y,Z/Q) |
| Z/Q Display Model | Length or Angle |
| Angle Display Model | Degree, Minutes and Second or Degree |
| Linear Scale Signal | TTL square-wave or AC sine wave of two 90 ° phase angle difference, drive capacity larger than 10MA |
| Linear Scale Resolution | 0.1um,0.2um,0.5um, 1um,2um,5um |
| Baud Rate | 4800,9600,14400,19200,38400,57600 |
| Data Output Port | RS232，DB-9 Parent interface |
| Operation Keyboard | Sealed Silicone touch-type keyboard |
| Expansion port | Foot Switch, Printer, Optical Edge Finder, etc |
| Input Power Supply | AC90V-240V,15W |
| Operation Environment | Working Temperature： 0 ℃～40 ℃；Storage Temperature：-10 ℃～60℃；Relative Humidity：<90%RH |
Product Details
Company Features
1. Sinowon Innovation Metrology Manufacture Limited., a nation-renowned electronic linear scale developer and manufacturer, is known for its strong R&D and manufacturing competence in this field.
2. We have a group of R&D professionals. With their years of R&D knowledge in the industry, they are able to develop innovative products according to the newest trends.
3. With the improvement of digital readout industry, Sinowon will still dedicate into developing, producing, selling and servicing with high standard. Get info! To pursue optical comparator accessories , digital readout systems will be the eternal tenet of Sinowon Innovation Metrology Manufacture Limited.. Get info! machine digital readout is the cardinal tenet of Sinowon Innovation Metrology Manufacture Limited.'s operation. Get info! Sinowon Innovation Metrology Manufacture Limited. will seize the opportunity to continue the rapid and healthy development of itself in digital measuring device industry. Get info!
