Sinowon digital rockwell hardness test procedure personalized for small areas

Model:

DigiRock SR2

Code#:

811-310

Warranty:

12 month

Delivery Time:

15-30days

Standard:

GB/T230.2, JIS Z2245, EN-ISO 6508 , ASTM E-18

Certificate:

Inquiry

Sinowon digital rockwell hardness test procedure personalized for small areas 3

Product Feature

◆ DigiRock SR2 can test both Rockwell and Superficial Rockwell hardness scales.

◆ Manually switch 3kgf and 10kgf initial force, to test rockwell and superficial rockwell scales.

◆ Dial reading, resolution is 0.5HR.

◆ Motorized loading/dwelling/unloading to make precision force and excellent results.

Specification

Product Name	Electronic Twin Rockwell Hardness Tester
Model	DigiRock SR2
Code#	811-310
Rockwell Scales	HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK,HRL, HRM, HRP, HRR, HRS, HRV
Rockwell Force	60kgf(588.4N)、100Kgf(980.7N)、150kgf(1471N)
Superficial Rockwell Scales	HR15N、HR30N、HR45N、HR15T、HR30T、HR45T HR15W、HR30W、HR45W、HR15X、HR30X、HR45X、HR15Y、HR30Y、HR45Y
Superficial Rockwell Force	15Kgf(147.1N),30Kgf(294.3N),45Kgf(441.3N)
Dwell Time	Adjustable 2-60s
Reading	Dial Reading
Resolution	0.5HR
Loading Control	Motorized loading/dwelling/unloading
Max. Height Of Specimen	175mm
Instrument Throat	165mm
Power supply	AC220V/50Hz;AC110V/60Hz
Dimension(LxWxH)	546x182x755mm
Packing Dimension	620x460x870mm
Gross/Net Weight	120Kg/90Kg
Execution Standard	GB/T230.2, JIS Z2245, EN-ISO 6508 , ASTM E-18

Application

Rockwell B Scale HRB: Copper alloys, soft steels, aluminum alloys, malleable iron, etc.

Rockwell C Scale HRC: Steel, hard cast irons, pearlitic malleable iron, titanium, deep case hardened steel, and other materials harder than B100.

Rockwell A Scale HRA: Cemented carbides, thin steel, and shallow case-hardened steel.

Software Introduction

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
