Sinowon durable hardness testing machine series for small parts1
Model:
DigiRock BRV2
Code#:
811-140
Warranty:
15-month
Delivery Time:
15-30 days
Standard:
ISO 6508，ASTM E18，GB/T230
Certificate:
CE
Product Details
With the dedication to pursue excellence, Sinowon strives for perfection in every detail.Good materials, advanced production technology, and fine manufacturing techniques are used in the production of optical measurement instruments. It is of fine workmanship and good quality and is well sold in the domestic market.
Product Comparison
Sinowon carefully selects quality raw materials. Production cost and product quality will be strictly controlled. This enables us to produce vision measuring machine which is more competitive than other products in the industry. It has advantages in internal performance, price, and quality.Supported by advanced technology, Sinowon has a great breakthrough in the comprehensive competitiveness of vision measuring machine, as shown in the following aspects.
1. In the design of Sinowon the rockwell hardness test, various elements have been thought of. They involve physical stress points, weight distribution, arch support, and various foot shapes.
2. The superior performance of the product is crowd-pleasing in the market.
3. The use of this product in consumer products is very common and it is generally considered safe for people to use.
4. Because the product can be joined together or connected in some way, people can completely customize the kind of space they want.
Product Feature
◆ DigiRock BRV2 is a universal hardness testing instrument for the measurement of Brinell, Rockwell and Vickers scale.
◆ DigiRock BRV2 equips 7-testing-foce and 5-indenter, it is universal to measure a lot of material.
◆ DigiRock BRV2 dwell time from 1 to 60S can be setup by the “time key” on the panel, it is much convenient than the setup on the manual hardness tester;
◆ DigiRock BRV2 force knob adopts the metal material to replace the plastic, it improves the instrument using-life greatly;
◆ DigiRock BRV2 loading, dwell and unloading is driven by electronic motor automatically, doesn’t need the operator to handle it, it eliminates the human operating error maximum.
Specification
| Product Name | Motorized Universal Hardness Tester |
| Model | DigiRock BRV2 |
| Code# | 811-140 |
| Rockwell Scales | HRA, HRB, HRC |
| Rockwell Testing Force | 60Kgf(588.4N)、100Kgf(980.7N)、150Kgf(1471N) |
| Brinell Scales | HBW1/30、HBW2.5/62.5、HBW10/100、HBW2.5/187.5 |
| Brinell Testing Force | 31.25Kgf(306.5N)、62.5Kgf(612.9N、187.5Kgf(1839N) |
| Vickers Scales | HV 30、HV100 |
| Vickers Testing Force | 30Kgf(294.2N)、100Kgf(980.7N) |
| Rockwell Hardness Indication | Analogue Display |
| Rockwell Resolution | 0.5HR |
| Loading Control | Motorized |
| Magnification of Microscope | Brinell:50x; Vickers:100x |
| Dwell Time | Adjustable 2~60s |
| Max. Height Of Specimen | Rockwell:170mm; Brinell, Vickers:140m |
| Instrument Throat | 165mm |
| Dimension(LxWxH) | 546x182x755mm |
| Packing Dimension | 620x460x870mm |
| Power supply | AC220V/50Hz;AC110V/60Hz |
| Gross/Net Weight | 120Kg/90Kg |
| Execution Standard | ISO 6508，ASTM E18，GB/T230 |
Company Features
1. Over the years, Sinowon Innovation Metrology Manufacture Limited. has been maintaining a leading position in the industry. We develop, produce, and supply the rockwell hardness test for years.
2. The team in Sinowon Innovation Metrology Manufacture Limited. is concentrated, capable and active.
3. Sinowon Innovation Metrology Manufacture Limited. regards high-quality service as the life. Check now! Sinowon Innovation Metrology Manufacture Limited. is able to manufacture your hardness testing machine products to the highest quality at the best possible price. Check now! Sinowon Innovation Metrology Manufacture Limited. firmly sticks to customer's needs to improve rockwell hardness of steel . Check now! Sinowon makes determined decisions to be the leading supplier in rockwell hardness tester industry. Check now!
