Sinowon hot selling microhardness test from China for thin materials

Company Advantages
1. Sinowon hardness tester machine price is developed and constantly improved for its technical performance, making it perfectly suitable for innovative and future-oriented buildings. A team of experienced talents is gathered to support the product sales
2. People who have bought this product a year ago said that there is no rust or crack or even scratch on it, and they are going to purchase more. Imported materials and accessories are used in product manufacturing
3. This product can withstand the most stringent industrial conditions. It is made of new materials, such as improved steel alloys and other composites, which are durable enough. It, up to the requirements from different industries, is widely applied
4. This product guarantees good strength. It is durable and has proven to be effective to protect items. It is well recognized by more than 5000 customers
5. This product has the characteristics of stable and reliable operation. It maintains the highest level without interruption. The production is supported by professional engineers

◆ It adopts die-cast body, stability is much higher than in the mechanical performance of sheet metal welding machines;

◆ It is equipped with 10X and 40X HD lens and HD USB camera, the instrument measured images in optical imaging system and video of great quality;

◆ Combined with MV-1000 video measuring devices, It improves efficiency, reduces visual fatigue of the operator.

◆ Testing very thin materials like foils, thin pieces, coatings layers, etc;

◆ Measuring hardness of the surface of a part, small parts or small areas;

◆ Measuring individual micro-structures;

◆ Measuring the depth of case hardening by sectioning a part and making a series of indentations to describe a profile of the change in hardness.

Product Name		Micro Hardness Tester with Measurement Monitor
Model		MV-1000V
Code#		823-101V
Loading force	N	0.098、0.246、0.49、0.98、1.96、2.94、4.90、9.80
	Kgf	10、25、50、100、200、300、500、1000
Indentation Measuring Device		MV-100
Switch of Objectives and Pressure Switch		Auto-turret
Loading Control		Auto Loading, Dwell and Unloading
Magnification of Objective		Observation：10x/40x；Measurement：10x/40x
Video System		CMOS Measuring Eyepiece, 8 "Display
Dwell Time		5-60s
Measuring Range		1HV-2967HV
X-Y Anvil		Size：100X100mm；  Travel：25mm X 25mm;Resolution：2um
Maximum Height and Width of Specimen		Maximum Height：70mm; Maximum Width：95mm
Power supply		AC220/50Hz; AC110V/60Hz
Dimension		425X245X490mm
Gross/Net Weight		45kg/35Kg
Executive Standard		GB/T4340.2, EN-ISO6507,ASTME10-08,ASTME-384

Company Features
1. The cutting-edge technology adopted in microhardness test helps us win more and more customers.
2. Sinowon Innovation Metrology Manufacture Limited. adheres to the concept of customer first. Get quote!
