Sinowon quality Video Microscope personalized for soft alloys
Model:
VM-200
Code#:
451-420
Warranty:
12 month
Delivery Time:
15-30days
Certificate:
CE
Company Advantages
1. Sinowon digital measuring microscope is elaborately manufactured using the latest advanced technology and production method. The quality is reliable and the service life is long
2. In the local the product enjoys a certain reputation and visibility. It, up to the requirements from different industries, is widely applied
3. The manufactured Video Microscope has such merits of digital measuring microscope as to be used in best digital microscope camera area. It is supported by multiple languages say English, Turkish, and German
4. The most important function offered by digital measuring microscope is Video Microscope . The product can be controlled in a motorized way, to eliminate errors caused by manual operation
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. has become the largest production base for Video Microscope in Pearl River Delta. As time goes by, the technical strength of Sinowon continues to increase.
2. We respect the international quality system in the production process vision microscope .
3. Sinowon implements innovative techniques to create high quality digital microscope camera . Sinowon Innovation Metrology Manufacture Limited. strives to provide customers with better service and support! Check it!
1. Sinowon digital measuring microscope is elaborately manufactured using the latest advanced technology and production method. The quality is reliable and the service life is long
2. In the local the product enjoys a certain reputation and visibility. It, up to the requirements from different industries, is widely applied
3. The manufactured Video Microscope has such merits of digital measuring microscope as to be used in best digital microscope camera area. It is supported by multiple languages say English, Turkish, and German
4. The most important function offered by digital measuring microscope is Video Microscope . The product can be controlled in a motorized way, to eliminate errors caused by manual operation
Application:
Product Feature
◆ Integral design, exquisite, fashion, generous;
◆ With high definition 0.7~4.5X parallel continue zoom lens, it is more convenient and fast to switch objective magnification;
◆ With adjustable LED surface reflection illumination, is able to control brightness independently;
◆ With 2 million pixel auto focus camera, no need to waste time for manual focus frequently.
Specification
| Product Name | Auto Focus Video Microscope |
| Model | VM-200 |
| Code# | 451-420 |
| Electronic Magnification | 32X~206X( VGA 4:3 21”Monitor；） |
| Optical Objective | 0.7X~4.5X Horizontal Zoom Lens |
| Zoom ratio：6.5:1 | |
| 0.5X C-mount Camera Adapter | |
| Camera Parameters | 2 million pixel (1920*1080) |
| Image Size:1/2.86” | |
| Frames Per Second：30fps | |
| Camera Function | Auto Focus |
| Cross Line | |
| Photograph and Video Record | |
| Output： HDMI | |
| White Balance; Brightness Control; Digital Noise Reduction | |
| Illumination | Surface: Adjustable LED Surface Illumination |
| Ring Fiber Illumination Optional | |
| Microscope Stand | Z-axis Travel: 100mm |
| Coarse Lifting System | |
| Electrical Parameters | AC90~240V；50~60HZ |
| Dimension | 310*285*500 mm |
| Weight | 6Kg |
Accessories:
| Product Name | Specification |
| Microscope Main Body | VM-200 |
| Power Adapter | DC5V（Camera）、DC12V（Illumination） |
| Monitor | Optional 4:3 21.5” |
| Operation Manual/Warranty Card/Certificate/Packing list | VM-200 |
Field of View:
| Auxiliary objective | Field of view （0.5X Camera Adapter) | Remark | |||||||||||||||||||
| 0.7X | 1X | 2X | 3X | 4X | 4.5X | ||||||||||||||||
| Length | Width | Diagonal | Length | Width | Diagonal | Length | Width | Diagonal | Length | Width | Diagonal | Length | Width | Diagonal | Length | Width | Diagonal | ||||
| 0.5X WD:108mm | Magnification 0.18X-1.12X | Optional | |||||||||||||||||||
| 25.29 | 22.86 | 34.09 | 17.70 | 16.00 | 23.86 | 8.85 | 8.00 | 11.93 | 5.90 | 5.33 | 7.95 | 4.43 | 4.00 | 5.97 | 3.93 | 3.56 | 5.30 | ||||
| 1.0X WD:91mm | Magnification 0.35X-2.25X | Standard | |||||||||||||||||||
| 12.64 | 11.43 | 17.04 | 8.85 | 8.00 | 11.93 | 4.43 | 4.00 | 5.97 | 2.95 | 2.67 | 3.98 | 2.21 | 2.00 | 2.98 | 1.97 | 1.78 | 2.65 | ||||
| 2.0X WD:35.3mm | Magnification0.70X-4.50X | Optional | |||||||||||||||||||
| 6.32 | 5.71 | 8.52 | 4.43 | 4.00 | 5.97 | 2.21 | 2 | 2.98 | 1.48 | 1.33 | 1.99 | 1.11 | 1.00 | 1.49 | 0.98 | 0.89 | 1.33 | ||||
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. has become the largest production base for Video Microscope in Pearl River Delta. As time goes by, the technical strength of Sinowon continues to increase.
2. We respect the international quality system in the production process vision microscope .
3. Sinowon implements innovative techniques to create high quality digital microscope camera . Sinowon Innovation Metrology Manufacture Limited. strives to provide customers with better service and support! Check it!
