Sinowon vexus portable hardness tester series for measuring
1. Sinowon portable hardness tester is of guaranteed quality. It is tested for proper color, abrasion resistance, waterproofness, weight and hand properties in the manufacturing process. Its packing is made seriously to guarantee the safety during shipment
2. The product can be widely applied to different fields. The product has been installed in many countries such as the US, Canada, Mexico, and Germany
3. Our professional quality control team and authoritative third party have carefully and rigorously reviewed the product quality. The product is designed by professional designers to be user-friendly
Product Feature
◆ DigiRock HR1 analogue gauge resolution is 0.5HR, it is useful to improve the reading accuracy than traditional 1HR resolution;
◆ DigiRock HR1 force knob adopts the metal material to replace the plastic, it largely improves the instrument using-life ;
◆ DigiRock HR1 loading, dwell and unloading is buffering by oil pump,it eliminate the operator' s tiredness ;
◆ DigiRock HR1 intenter protector is available to improve the using lifetime of indenter.
Specification
| Product Name | Manual Rockwell Hardness Tester |
| Model | DigiRock HR1 |
| Code# | 811-110 |
| Rockwell Scales | HL,HRC ,HRB, HRA, HV,HB,HS |
| Preliminary Test Force | 10kgf(98N) Permitted Error：±2.0% |
| Addtional Test Fore | 60Kgf(558.4N),100Kgf(980.7N),150Kgf(1471N) |
| Dwell Time | Adjustable 1-60s |
| Hardness Indication | Analogue Display |
| Resolution | 0.5HR |
| Loading Control | Manual |
| Max. Height Of Specimen | 175mm |
| Instrument Throat | 165mm |
| Power supply | No Electronic |
| Dimension(LxWxH) | 546x182x755mm |
| Packing Dimension | 620x460x870mm |
| Gross/Net Weight | 120Kg/90Kg |
| Execution Standard | ISO 6508，ASTM E18，GB/T230 |
Application
Rockwell B Scale HRB: Copper alloys, soft steels, aluminum alloys, malleable iron, etc.
Rockwell C Scale HRC: Steel, hard cast irons, pearlitic malleable iron, titanium, deep case hardened steel, and other materials harder than B100.
Rockwell A Scale HRA: Cemented carbides, thin steel, and shallow case-hardened steel.
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is an expert who creates rockwell tester for sale in the value chain from product development to manufacturing.
2. Our reputation is well deserved. Our products and technologies continue to set new standards in performance and durability, and we have many patents in design, process, technology and materials science.
3. Sinowon aims to solve the business and technical challenges to adapt to different development phases. Get quote!
