analog computer vision price inquire now for precision industry

Company Advantages
1. It is a great addition for computer vision price to design u vision software cost . Its quality and accuracy are improved every year
2. This product is well-known in the industry for its huge economic results. It is supported by multiple languages say English, Turkish, and German
3. To ensure the product quality, advanced management method of ISO 9000 has been introduced. Imported materials and accessories are used in product manufacturing
4. This product has an extremely high level of performance, which is guaranteed by the quality control system. It is aimed at more than 60 countries and regions for exports
5. Our QC team implements a strict quality control system and perfect monitor method. Its packing is made seriously to guarantee the safety during shipment



EFFICIENT

◆Precise

◆Rapid

◆Non-contact

VERSATILE

◆Distance and topography

◆Wide thickness measuring range

◆Measurements on all surfaces

◆Inline and offline

User Friendly

◆Maintenance-free

◆Simple to integrate

◆Nondestructive measurement

◆Robust

◆Automatic light control

Application	Distance,   thickness
Measurements /second	32   - 2000
Interferometric   Measuring Range 1)	3   μm - 180 μm
Chromatic   Measuring Range	Depends   on optical probe
Pitch   Error 2)	<   10 -3
Linearity   Error 2)	<   3.3 x 10 -4 x upper measuring range limit
Resolution	10   -7 x upper measuring range limit
Reproducibility	9   x 10 -5 x upper measuring range limit
Number   of measuring channels	1
Synchronization   with external devices	Trigger   input, synchronizing output, 3 encoder inputs
Interface	USB,   RS-232, RS-422, 2 x analog (0 V to 10 V, 16 Bit), LVDT 3)
Transfer   Rate	RS-232   (9600 - 921600 Baud); RS-422 (9600 - 921600 Baud); USB:   virtual comport (921600 Baud)
Light   Source	LED
Length   Optical Fiber4)	2   m - 40 m (multi mode fiber)
Fiber   Connection	E   2000
Operating   Temperature	+5°C   up to +50°C
Dimension   (w x h x d)	200   mm x 100 mm x 93 mm
Weight	1.1   kg
Supply   Voltage	16   - 30 V DC (with separate power supply 90 - 264 V AC)
Rated   Power	10   W

¹⁾ Optical length

²⁾ Measuring accuracy = linearity error + (pitch error x measuring value)

³⁾ Optional

⁴⁾ Metal cover up to 15 m also available

Company Features
1. With larger manufacture scale, Sinowon Innovation Metrology Manufacture Limited. has made a stride in international stage. Sinowon Innovation Metrology Manufacture Limited. is solid and powerful according to its technical foundation.
2. The company possesses excellent technical and R&D team who develop innovative products with rigorous attitude and strict standards and proactively push the industry moving forward.
3. This company has established a strong client base. By making full use of the company's yellow pages, we identify the mighty competitors and learn from their strong points and offset our weak points. This helps us grow stronger to win more customers. In order to meet customers' satisfactions, Sinowon Innovation Metrology Manufacture Limited. has built a complete service system to solve all possible problems. Please contact us!
