A professional manufacturer of measuring & testing equipment.

application of brinell hardness test electronic portable vision Warranty Sinowon 1
application of brinell hardness test electronic portable vision Warranty Sinowon 2
application of brinell hardness test electronic portable vision Warranty Sinowon 1
application of brinell hardness test electronic portable vision Warranty Sinowon 2

application of brinell hardness test electronic portable vision Warranty Sinowon

Model:
SHB-3000B
Code#:
831-101
Accuracy:
≤±3.5%
Warranty:
12 month
Delivery Time:
15-30days
Standard:
GB/T231.2, JJG150, EN-ISO 6506 ASTM E10-12 JIS Z2243
Certificate:
CE
Inquiry
Product Comparison
Compared with products in the same category, 's core competencies are mainly reflected in the following aspects.
  • application of brinell hardness test electronic portable vision Warranty Sinowon 3
    application of brinell hardness test electronic portable vision Warranty Sinowon 4
Product Details
Next, will present you with the specific details of .
  • application of brinell hardness test electronic portable vision Warranty Sinowon 5
Company Advantages
1. Our established reputation has helped us in establishing a wide client base across China. The product is highly praised in many exhibitions such as Shanghai Electronica China Show
2. The success of a company depends on whether you can understand and meet the customers' current/future demands and, if possible, try to exceed their demands.A quality control system is implemented for the product
3. All of our products are brinell hardness test, providing in modern and stylish designs. The quality is reliable and the service life is long
4. brinell hardness has better performance than any other similar products and is well accepted by customers. The product performs well in program control and material use reduction
5. It is well recognized by more than 5000 customers. our expertise and industry knowledge has helped us gain an edge over the industry counterparts.
6. With the huge application prospect, the product is profoundly preferred by our customers. More than 10,000 pcs have been delivered and installed

application of brinell hardness test electronic portable vision Warranty Sinowon 6



Product Feature


 Electronic communication switch.

 Solid construction, good rigidity, precise, reliable, durable, high efficiency.

 High precision reading microscope measurement system.

◆ Widely used in quality control, strong adaptability to working environment.

 In line with GB/T231.2, ISO 6506-2 ,ASTM E10.



Application


Testing Brinell hardness of ferrous, non-ferrous metal and bearing alloy materials. Wide application range, especially used in precision measurement of parallel plane.  What’s more, measurement of curved surface is stable and reliable.



Specification



Name

Brinell Hardness Tester

Model

SHB-3000B

Code#

831-101

Loading ForceKgf

62.5Kgf, 100Kgf, 125Kgf, 187.5Kgf, 250Kgf,  500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf

N

612.9N, 980N, 1226N, 1839N, 2452N, 4900N, 7355N, 9800N, 14700N, 29400N

Brinell Range(8-450) HBS,(8-650) HBW
Hardness DisplayCheck the table of Brinell Hardness scale
Microscope

Analogue 20x Microscope

Vertical Space

230mm

Horizontal Space

120mm

Dimension

700 x268 x842mm

Gross/Net Weight

240Kg/210Kg

Power Supply

AC 220V/110V±5%,50~60 Hz

Conform Standard

GB/T231.2, JJG150, EN-ISO 6506 ASTM E10-12  JIS Z2243

Accuracy

Hardness RangePermitted ErrorRepeatability
HBW≤ 125≤± 3.5%≤ 3.5%
125<HBW≤225≤± 2.5%≤ 3.0%
HBW> 225≤± 2.0%≤ 2.5%





Company Features
1. With the help of professional employees, Sinowon enjoys a good reputation globally. - The Sinowon brand has always attracted more market customers.
2. Sinowon Innovation Metrology Manufacture Limited. also set up a new production fast lane, cutting turnaround time to less than application of brinell hardness test for some key items. - Applying practical brinell hardness machine into the process of makes brinell hardness test popular among customers.
3. We Will Try Our Best To Comply With Your Request,As A Professional Factory In China, Our Main Products Include All Kinds Of brinell hardness, king brinell hardness tester, For More Detailed Information, Please Contact Us, Pls Visit Our Website Without Hesitation, Contact Us! - Our deft professionals fabricate the stand using quality raw materials and smart technology.
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
