efficient metallurgical equipment with good price for medical devices1

Company Advantages
1. The material selection of metallurgical equipment always take metallurgical polishing machine into account.
2. Sinowon's product is subject to a professional quality inspection team.
3. Our metallurgical equipment can be in high productivity all round the clock.
4. Sinowon Innovation Metrology Manufacture Limited. makes sure quality control system is implemented effectively.
5. Sinowon's R&D team will design and manufacture metallurgical equipment according to customer's different needs.

◆ Powerful motor to reduce cutting time and provide high productivity

◆ Smart feed. The machine can adjust the feed speed in real time with the load changes

◆ Cutting modes: Y-continuous, Y-pulse, Z-continuous, Z-pulse, slicing (different model, different cutting mode)

◆ Versatile industrial joystick with X, Y, Z axis. Easy to use

◆ 8 inch color touchscreen for simple operation and user friendliness

◆ Electrical brake for faster stopping of the blade

◆ Chamber illumination with LED

◆ Aluminum casting base, powder coated

◆ T-slot Table made of stainless and aluminum alloy

◆ Fast Cam Locking Vises, made of 304 stainless steel

◆ Left cover made of composites by integral molding

◆ Mobile plastic recirculation coolant tank

◆ Independent pump for cleaning the chamber

◆ Optional laser alignment aid

Description	AC-300XYZ	AC-300YZ	AC-300Z
Y Feed	Automatic
Z Feed	Automatic	Automatic	---
X Feed	Automatic	○Manual	○Automatic○Manual
Cutting mode	Continuous, Pulse	Continuous, Pulse	Continuous, Pulse
Blade(mm)	300*32*1.8
Blade speed (rpm)	500-3000
Table Dimensions (WxD,mm)	350*260
X Travel	80mm
Cooling	Automatic/manual
Main Motor	3.0KW
Power	110/220V AC, 50-60Hz,   1 Phase/3 Phase
Accessories
Diamond Blade	○	○	○
SiC blade	○	○	○
Alumina Blade	●	●	●
Fast Cam Locking Vises	●	●	●
Vertical Clamping vise	○	○	○
Laser alignment aid	○	○	○
Plastic tank	●	●	●
Plastic tank with magnetic filter	○	○	○
Cutting fluid	○	○	○
Centrifugal separator	○	○	○

●Standard○Option

Company Features
1. With a large-scale factory and professional production line, Sinowon Innovation Metrology Manufacture Limited. is considered a reliable supplier of metallurgical equipment .
2. The factory has strict quality management from the initial production stage. From raw materials selection, product design, production, to the complete package, we always guide our actions adhering to the ISO 9001 international quality system.
3. Sinowon Innovation Metrology Manufacture Limited. keeps concentrated on superior service for customers. Inquire! Sinowon Innovation Metrology Manufacture Limited. has established a perfect sales and service network throughout the world. Inquire! Sinowon has been following the management idea of metallurgical polishing machine to serve the customers wholeheartedly. Inquire!
