hot selling tensile strength measuring instrument from China for commercial

Company Advantages
1. Sinowon testing of materials with universal testing machine has gone through a range of performance tests. They are rub fastness, colorfastness, tearing strength, fabric tension strength, and washing resistance. It can be customized according to customers' needs
2. It is well-known that Sinowon has good quality tensile strength measuring instrument after-sales service. The production is supported by professional engineers
3. The product has reliable working performance. It is able to withstand impact and high loading working conditions without sacrificing its efficiency. A quality control system is implemented for the product

◆ The material testing is driven by AC servo motor stably;

◆ The linear motion is ensured by double precision ball screw rod smoothly;

◆ The columns are protected by aluminum shell with sandblasted surface perfectly;

◆ The base cover is made of high-grade ABS plastic with spray coating, which is durable and beautiful;

◆ The fine adjustment switch is standard delivery for up and down stroke;

◆ The different functional grips can be replaced by the quick-release-clamp easily.

Product Name	Universal Material Testing Machine
Model	Vexus MT20-700	Vexus MT20-1000	Vexus MT20-1500
Test Stroke	700mm	1000mm	1500mm
Capacity	10N, 20N, 50N, 100N, 200N, 500N, 1KN, 2KN, 5KN, 10KN, 20KN(can select double capacities preparation)
Display	Computer display mode
Force Resolution	1/500,000
Force Accuracy	≤±0.3%
Stroke Resolution	0.005mm
Control Mode	All computerized operation mode
Test Width	Ø420mm
Test Speed	0.1~1000mm/min, can set by computer, with up & down fast adjustment button of grips
Force Unit Switch	Kgf, N, Ibf, g, ton, Mpa
Stop Mode	Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function
Machine Dimension	72×52×130cm(W×D×H)
Machine Drive	Servo motor drive, synchronous wheel and precision ball screw drive
Power	400W
Machine Weight	Approx 115kg
Power Supply	220V 50/60HZ 10A
Standard Device	1 set of grips, computer software, USB computer connection wire
Optional	Computer and Grips

◆ MS100 Test & Control System is designed to work PC Electronic Universal Testing Machines, PC Hydraulic Universal Testing Machines and PC Compression testers, which can make the testing of tensile, compression, bending, shearing, tearing and peeling test, etc.

◆ MS100 has the functions of data collection, save, processing and printing test result, it can calculate max force, yield strength, average peeling force, max deformation, yield point, elastic modulus and other parameters; can conduct curve graphics processing, multi-sensor support, flexible data processing, MS-ACCESS database support, and so on.

Company Features
1. Established years ago, Sinowon Innovation Metrology Manufacture Limited. is one of the main manufacturers of testing of materials with universal testing machine in China with a solid industry background and related experience. The workshop, equipped with many first-class testing facilities that run under the inspection of the strict management control system. This makes sure every production stage is under inspection and products are under quality control.
2. Since inception, we have won national awards on technology developments, such as product innovation and creativity. These awards are strong supporting evidence of our R&D ability.
3. With the help of our efficient sales strategy and extensive sales network, we have established successful partnerships with many customers from North America, South East Asia, and Europe. We take a responsible approach in every aspect of our operations. We are committed to managing and reducing production waste as possible.
