A professional manufacturer of measuring & testing equipment.

irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 1
irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 2
irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 1
irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 2

irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon

Model:
Vexus SHR-187.5D
Code#:
811-161
Warranty:
12 month
Delivery Time:
15-30days
Standard:
ISO 6508,ASTM E18,JIS Z2245,GB/T230
Certificate:
CE
Inquiry
Product Comparison
optical measurement instruments has the following advantages: well-chosen materials, reasonable design, stable performance, excellent quality, and affordable price. Such a product is up to the market demand.Sinowon's optical measurement instruments has better performances in the following aspects.
  • irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 3
    irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 4
Product Details
Sinowon pursues excellent quality and strives for perfection in every detail during the production.optical measurement instruments is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.
  • irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 5
Company Advantages
1. Sinowon types of hardness testing machine is constructed from well-chosen raw materials.
2. All the difference in texture and feature sets this product apart from the competition.
3. Sinowon Innovation Metrology Manufacture Limited. has been concentrated on producing high quality rockwell hardness tester for years.
4. Sinowon Innovation Metrology Manufacture Limited. has been praised for our fast response for complaints.

irock types of hardness testing machine dr2ds2tr2 for thin materials Sinowon 6



Product Feature


 Vexus SHR-187.5 is a universal hardness testing instrument for the measurement of Brinell, Rockwell and Vickers scale.

 Vexus SHR-187.5 equips 7-testing-foce and 5-indenter, it is universal to measure most of metal material.

 Vexus SHR-187.5 dwell time from 2 to 60S can be setup on LCD panel, it is much convenient than the setup on the manual hardness tester;

◆ Vexus SHR-187.5  loading ,dwell and unloading is driven by electronic motor automatically , doesn’t need the operator to handle it, it eliminates the human operating error maximum ;

◆ Vexus SHR-187.5 doesn’t need the operator to read and check the hardness scale table ,it will compute and display the testing result once press the key of digital length sensor.



Specification



Product NameDigital Universal Hardness Tester
ModelVexus SHR-187.5D
Code#811-161
Rockwell ScalesHRA, HRB, HRC
Rockwell Testing Force60Kgf(588.4N)、100Kgf(980.7N)、150Kgf(1471N)
Brinell ScalesHBW1/30、HBW2.5/62.5、HBW10/100、HBW2.5/187.5
Brinell Testing Force31.25Kgf(306.5N)、62.5Kgf(612.9N、187.5Kgf(1839N)
Vickers ScalesHV 30、HV100
Vickers Testing Force30Kgf(294.2N)、100Kgf(980.7N)
Rockwell Hardness Indication

Digital LCD display

Rockwell Resolution0.1HR
Loading ControlAutomatic
Magnification of MicroscopeBrinell:37.5x; Vickers:75x
Dwell TimeAdjustable 2~60s
Max. Height Of Specimen

Rockwell:170mm; Brinell, Vickers:140m

Instrument Throat165mm
Dimension(LxWxH)520 x215 x700mm
Packing Dimension630 x440 x960mm
Power supplyAC220V/50Hz;AC110V/60Hz
Gross/Net Weight120Kg/90Kg
Execution StandardISO 6508,ASTM E18,JIS Z2245,GB/T230


Application




Rockwell B Scale HRB: Copper alloys, soft steels, aluminum alloys, malleable iron, etc.

Rockwell C Scale HRC: Steel, hard cast irons, pearlitic malleable iron, titanium, deep case hardened steel, and other materials harder than B100.

Rockwell A Scale HRA: Cemented carbides, thin steel, and shallow case-hardened steel.




Company Features
1. Sinowon, thanks to the rockwell hardness tester , is known to more and more clients and end users.
2. It proves to be efficient for Sinowon to introduce high technology.
3. Sinowon Innovation Metrology Manufacture Limited. is able to create the highest valued rockwell hardness unit at the best price. Check it! Sinowon Innovation Metrology Manufacture Limited. aims to improve the user experience and spread the brand reputation by word-of-mouth. Check it! With the development of China's market economy, Sinowon Innovation Metrology Manufacture Limited. vigorously implement the strategy of internationalization and diversification. Check it!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
