Sinowon cmm measuring machine wholesale for measuring

Company Advantages
1. The fabrics used in Sinowon portable coordinate measuring machine comply with global organic textile standards. They are certified by Oeko-Tex. The product is well known for high accuracy and great stability
2. Through a rigorous quality control system, Sinowon Innovation Metrology Manufacture Limited. has ensured the stability of all products' quality. It has been marketed successfully for 12 years, thanks to the excellence in quality and technology
3. This product has a good color fastness. Its fabric remains in its original color after long periods of use and multiple washing. The product is CE certified for the European market
4. The product features an easy operation. It has a simple operation instruction which can support its powerful processing flow to finish its expected tasks. The product is designed by professional designers to be user-friendly
5. The product is built to last for a long time. The mechanical structure is robust enough to withstand extreme working conditions, such as daily heavy use. The production is supported by professional engineers

◆ Granite fixed worktable, XZ axes are made of high performance aluminium alloy, Good temperature adaptability and faster movement speed.

◆ Granite worktable with integral “dovetail” guide in Y axis, eliminate the pitch and yaw ,also provides superior motion stability.

◆ Z axis air-balance with self-protection ,improve motion capability.

◆ Advanced synchronous belt drive system with non-slip and high stiffness, ensures high stability, lower noise.

◆ High precise, rigid, and pre-loaded air bearings on all axes, can ensure the guidance never be damped.

◆ Transmission system uses high-power  DC servo motor and new double level tape reducer to ensure rapid and accurate axes.

◆ RENISHAW tonic steel scale，Free expansion with the temperature change.

◆ Famous parts from all over the world are used in every important sub systems.

Measuring Strokes(mm)			Overall Dimension(mm)				Machine   Weight(Kg)	Max. Part Weight (Kg)
X	Y	Z	Lx	Ly	Lz
1000	1200	800	1690	2370	3150		2490	1800
Accuracy is according to ISO 10360 – 2
Maximum permissible error of indication of a CMM for size   measurement (μm)						Maximum permissible Probing Error (mm)
1.5 + 3L/1000						1.9
Scale   Resolution(μm): 0.1
Dynamic Performance
3D   positioning speed(mm/s)						3D acceleration(mm/s2)
530						1200

Room Required Specifications
Room Temperature	18～22°C
Temperature Gradient (in time)	1°C /h
Temperature Gradient (in time)	2°C /24h
Temperature Gradient (in the volume)	1°C /m
Humidity   Required Specifications
Relative   humidity	45-75％
Air   Supply System Required Specifications
Min.   air pressure	5bar [0.5 MPa]
Air   consumption	0.12-0.45m3/min
Electrical   requirements
Voltage	220 V ± 10%
Frequency	50/60 Hz
Max Power consumption	1500VA
Current	15 A
Allowed Maximum   Floor Vibration
Frequency Range	0 ~ 19 Hz      19~75 Hz > 75 Hz
Maximum Amplitude	0.0011 mm     0.0011~0.002 mm   0.002   mm
A good   earth ground (less than 4 W)   is required for reliable operation of the electrical controls.

Company Features
1. Focusing on R&D and production of cmm measuring machine , Sinowon Innovation Metrology Manufacture Limited. is one of the most popular exporters. Sinowon has auto mic computer-controlled machines to produce measuring machine .
2. In order to become a more competitive company, the introduction of talent and the development of new technologies have become especially important for Sinowon.
3. With a large scale of factory, Sinowon enjoys great reputation for its high quality products. We work hard to minimize our footprint by using thoughtful production processes and controls, as well as designing and supplying products that encourage environmental best practices.
