Sinowon polishing equipment design for medical devices
- Sinowon has always been providing advanced technology and sound after-sales service for customers.
1. The quality of Sinowon metallurgical testing equipment is guaranteed through a series of performance tests. Chemical tests, colorfastness, tensile strength, etc. are some of the common tests that are done on this product and materials used in it.
2. Our own quality control personnel and authoritative third parties have carefully inspected the product.
3. This product is a no brainer – it’s an undeniable marketing tool. Being beautifully designed, branded and easily recognizable, it works as a cool presentation of merchandise.
Product Feature
◆ Easy to use. One button start, automatic pressure loading, heating and cooling;
◆ High efficiency. New design of heating and cooling units significantly reduce the cycle time. Usually, the cycle time for 30mm diameter specimen is about 8 minutes;
◆ The two cylinders can work independently and have different mold size;
◆ User-friendly operation interface. Coloured HMI touch screen allows the users to set pressure, heating temperature, heatingtime and cooling time easily;
◆ Real-time temperature curve display;
◆ 10 memory modes which can set and save the parameters;
◆ For one cylinder, two specimens can be produced simultaneously with the use of a spacer;
◆ Three cooling modes: time, temperature, manual. It also has water-saving function;
◆ The cover is made of high temperature resistant composites by integral molding;
◆ Mobile plastic recirculation coolant tank is optional.
Specification
Description | AMP 5D | AMP 6D | AMP 7D | AMP 8D |
Operation | Automatic | |||
Pressure | Air | Air | Hydraulic | Hydraulic |
Cooling | Automatic/manual | |||
Mold | ○25 ●30 ○40 ○50mm, others can be customized | |||
Max Force（kgs） | 300 | 500 | 1200 | 4000 |
Max Tem（℃） | 180 | 180 | 200 | 200 |
Heater | 1.2KW | 2.4KW | 2.4KW | 3KW |
Dimension(WxDxH) | 600x560x430 | 600x560x430 | 540x560x430 | 540x560x430 |
Weight | 45Kg | 45Kg | 65Kg | 77Kg |
Power | 220V50Hz | |||
Air source | Need | Need | ||
Cooling Water | Need | |||
Mold Release | ○ | ○ | ○ | ○ |
Black Resin | ● | ● | ● | ● |
Green Resin | ○ | ○ | ○ | ○ |
Red Resin | ○ | ○ | ○ | ○ |
Conductive Resin | ○ | ○ | ○ | ○ |
Edge-protection Resin | ○ | ○ | ○ | ○ |
Transparent Resin | ○ | ○ | ○ | ○ |
Air filter | ● | ● | ● | ● |
Funnel&Spoon | ● | ● | ● | ● |
Drains | ● | ● | ● | ● |
●Standard○Option
Details
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is a sizable polishing equipment manufacturer in China.
2. Sinowon Innovation Metrology Manufacture Limited. is outfitted with some of the most innovative manufacturing machines.
3. Sinowon Innovation Metrology Manufacture Limited. attaches great importance to after-sales service and has established after-sales service team. Get price! Sinowon Innovation Metrology Manufacture Limited. provide decent production scheme with metallurgical testing equipment . Get price!
Mobile and whatsapp: +86-186-5556-9925
WeChat:186-5552-1738
Email: vanco@jiansongsh.com
| Specification _ Concrete Floor Grinder Polisher | ||||
| Model | S950 | S850 | S750 | S650 |
| Motor | 25HP | 20HP | 15HP | 15HP |
| Power | 380V | 380V | 380V | 380V |
| Current | 37amps | 30amps | 30amps | 22amps |
| Rotation speed small plate | 0-1800rpm | 0-1800rpm | 0-1800rpm | 0-1800rpm |
| Rotation speed big plate | 0-300rpm | 0-300rpm | 0-300rpm | 0-300rpm |
| Water tank | 40L | 40L | 40L | 40L |
| Weight | 435KG | 390KG | 380KG | 363KG |
| Grinding Pads | 12 | 12 | 12 | 12 |
| Grinding Heads | 4 | 4 | 4 | 4 |
| Working width | 950mm | 850mm | 750mm | 650mm |
JS Concrete Floor Grinder Polisher is the ideal machine to use when you want to quickly and effectively remove high spot.
Primarily intended for floor prep and removal of high spot
it find excellent performance for removing all kinds of coating such as varnish, glue, resin etc.
Another important application is to prepare very rough and uneven floor before proceeding with grinding machines
with Planetary system.
The removable diamond tool set is easy to access and replace.
The folding handle makes the machine compact and easy to transport.
For our JS Concrete Floor Grinder Polisher, you can use for concrete marble terrazzo granite epoxy stone Floor
We can custom to 220V or 380V to meet your working need.
Key features:
Easy Operation
Planetary Design
Better Stability
Wet and Dry use
Variable Speed Control
Mush higher production
Ideal for very large productivity
Total aluminum alloy gear box for a longer life.
Electronically adjustable working pressure.
Height-adjustable grinding heads make tool replacement easy
Used to create smooth, flat, swirl free finishes for the application of thin coatings and sealers.
- working width of machines range from 650mm to 950mm.
- the performance of the diamond grit segments and buttons are governed by grit size and bond material.
- progressive operations can lead from rough grinding to smooth glass-like finishes on natural stone or terrazzo.
- diamond floor grinding can be carried out wet or dry.
- the dust created when grinding dry can be controlled 100% with our V7 dust collector vacuum cleaner.
Marble polishing floor machine are generally the more lightweight , making them easier to manipulate.
Their design allows them to move in a straight line across the floor with relative ease,greater flexibility and less struggle for operators.
Thanks to their lightweight design, planetary grinders work best on less aggressive jobs, such as smoothing out a
concrete floor or preparing a residential garage floor for an epoxy coating. They can also be used for polishing
but generally require a skilled operator for this type of work.
Below are the diamond tools for these Concrete Floor Grinder Polisher
