A professional manufacturer of measuring & testing equipment.

sturdy stereo microscope factory price for steel products 1
sturdy stereo microscope factory price for steel products 2
sturdy stereo microscope factory price for steel products 3
sturdy stereo microscope factory price for steel products 4
sturdy stereo microscope factory price for steel products 5
sturdy stereo microscope factory price for steel products 1
sturdy stereo microscope factory price for steel products 2
sturdy stereo microscope factory price for steel products 3
sturdy stereo microscope factory price for steel products 4
sturdy stereo microscope factory price for steel products 5

sturdy stereo microscope factory price for steel products

Model:
VM-500Plus
Code#:
451-450P
Warranty:
12 month
Delivery Time:
15-30days
Certificate:
CE
Inquiry
Company Advantages
1. The quality control for Sinowon digital microscopes for sale is required to carry out thoroughly. Before packaging, it will be checked to make sure no impurities are included, and it will be packaged with thick corrugated paper to protect the four corners. The product is highly praised in many exhibitions such as Shanghai Electronica China Show
2. The potential users of this product are yet to be conquered. Its quality and accuracy are improved every year
3. It is not easily to get pilling. Its fibers are strong enough to not be easily damaged in the ways of washing, pulling or rubbing. It, up to the requirements from different industries, is widely applied
4. This product resists corrosion. It is made from Corten steel, sometimes called “weathering steel”. This is alloyed steel mixed with other metals that react when exposed to air and water. This reaction results in the formation of a layer of oxidization that prevents further corrosion of the metal. The product is well used in many large engineering projects
5. The product has a precise dimension. After it is produced, it will be checked using the dimension measuring equipment or coordinate measuring machine. More than 10,000 pcs have been delivered and installed


sturdy stereo microscope factory price for steel products 6

Application:
Incoming inspection, production inspection, material research, PCB and SMT inspection analysis, printing, textile inspection, biological anatomy, medical testing and other fields.





Watch





Solder PCB board



Aluminum Parts



Microstructure




 PCB





-












                        image.pngimage.png                      image.pngimage.png



 image.png image.png image.png image.png


Product Feature


Integral design, exquisite, fashion, generous;

Built-in FULL HD sensor and VGA integrated camera, can directly connect with the monitor to realize video image and can also use SD card to take picture or record video, which integrate video observation and image storage;

With high definition 0.7~4.5X parallel continue zoom lens, it is more convenient and fast to switch objective magnification;

With adjustable LED surface reflection illumination, is able to control brightness independently;

With 2 million pixel auto focus camera, no need to waste time for manual focus frequently.


Specification



Product NameAuto Focus Video Microscope
ModelVM-500Plus
Code#451-450
Electronic Magnification32X~206X( VGA 4:3 21”Monitor;)
Optical Objective0.7X~4.5X Horizontal Zoom Lens
Zoom ratio:6.5:1
0.5X C-mount Camera Adapter
Camera Parameters2 million pixel (1920*1080)
Image Size:1/2.86”
Frames Per Second:30fps
Camera FunctionAuto Focus
Cross Line
Photograph and Video Record
Output: HDMI
White Balance; Brightness Control; Digital Noise Reduction
IlluminationSurface: Adjustable LED Surface Illumination
Ring Fiber Illumination Optional
Microscope StandZ-axis Travel: 100mm
Coarse Lifting System
Electrical ParametersAC90~240V;50~60HZ
Dimension310*285*500 mm
Weight6Kg


Accessories



Product NameSpecification
Microscope Main BodyVM-500
Power AdapterDC5V(Camera)、DC12V(Illumination)
MonitorOptional 4:3 21.5”
Operation Manual/Warranty Card/Certificate/Packing listVM-500

Measurement Function




 VM-500Plus can measure straight lines, angles, concentric circles, parallel lines, point- to -line distance,  point and line to concentric circles, diameter, circumference and area, length and width of retangle, and can caculate circumference and area. It can measure the polygon and caculate its area. All the corresponding measurement report can be output to U disk.


sturdy stereo microscope factory price for steel products 22

Field of View




Auxiliary
objective
Field of view (0.5X Camera Adapter)
0.7X1X2X3X4X4.5XRemark
LengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonalLengthWidthDiagonal
0.5X
WD:108mm
Magnification 0.18X-1.12XOptional
25.2922.8634.0917.7016.0023.868.858.0011.935.905.337.954.434.005.973.933.565.30
1.0X
WD:91mm
Magnification 0.35X-2.25XStandard
12.6411.4317.048.858.0011.934.434.005.972.952.673.982.212.002.981.971.782.65
2.0X
WD:35.3mm
Magnification0.70X-4.50XOptional
6.325.718.524.434.005.972.2122.981.481.331.991.111.001.490.980.891.33



Field of View


sturdy stereo microscope factory price for steel products 23

sturdy stereo microscope factory price for steel products 24

Microscope Contrast



Comparision   parameterOptical Stereo MicroscopeVideo MicroscopeHD Microscope VM500Plus


Optical imageing qualityOKBadGood
Electronic imaging qualityXBadHD
Working DistanceShortShortLong W.D 164.43mm
Take pictureXPerhaps
Take videoXPerhaps
Auto focusXX
Manual focusFrequent OperationFrequent OperationAutomatic
Labor costHighHighSave Money
Vision protectionBadNot BadGood
PriceLow CostLow CostEqual Value
EfficiencyNot highNot highHigh
Evaluation:VM-500Plus   HD microscope save your money,save your time



Client List



Some of Clients List of Video Microscope
ItemModelClients Name
1VM-500Nidec Seimitsu Corporation(Dongguan/China)
2VM-500ASM Pacific Technology Ltd(Shenzhen/China)
3VM-500Vivo(Dongguan/China)
4VM-500Israeli Dealers
5VM-500Germany Dealers
6VM-500Italian Dealers
7VM-500Hungarian Dealers
8VM-500Korean Dealers
9VM-500Canadian Dealers





Company Features
1. With advanced technology applied in stereo microscope , we take the lead in this industry.
2. Sinowon always sticks to the client first principle. Call now!
