Sinowon Brand geology medical service mechanical industry electronic precision stereoscopic microscope
Model:
ST-524
Code#:
412x242
Accuracy:
≤3+L/200(um)
Warranty:
12 month
Delivery Time:
15-30days
Certificate:
CE
Product Comparison
Compared with other products in the same category, hardness testing machines produced by has the following advantages.
-
v s
1. Sinowon stereo microscope with camera designed for foreign customers are all unique and very successful. Its packing is made seriously to guarantee the safety during shipment
2. stereoscopic microscope has digital stereo microscope with stereo inspection microscope to handle bevel operations. Imported materials and accessories are used in product manufacturing
3. stereo microscope is equipped with a remote which monitors anywhere, anytime using a tablet or smartphone. The Gost certificate has been obtained for the Russian market
4. Your Inquiry Is Warmly Welcomed, It can be customized according to customers' needs,As A Leading Manufacturer Of optical microscope price, Sinowon Innovation Metrology Manufacture Limited. Has Amazing Manufacture And Sales Capacity, Welcome To Contact Us.
5. Oem Orders Are Welcomed, It is easy to operate, with fast speed,With Selected Material And Well Design, Sinowon Innovation Metrology Manufacture Limited. 'S stereo binocular microscopeS Are Popular With Our Customers, Pls Contact Us If You Need.
◆ Unique optic design;
◆ With long working distance and field of depth;
◆ Horizontal zoom knob, easy operation;
◆ Widely used for medical service, agriculture, geology, electronic precision mechanical industry and department.
Specification
| Model | ST-524 |
| Code# | 412x242 |
| Objective | 2x/4x |
| Eyepiece | With high eye point and wide field eyepiece SWH10X |
| Zoom Driver | Horizontal axial drive control knobs |
| Working Distance | 105mm |
| Interpupillary distance adjustment range | 52mm~76mm |
| Diopter Adjustment | ±6°(left drawtube) |
| Focus Range | 50mm (the square post is 100mm) |
| Diameter of the round post | Φ25mm |
| Distance between from the post center to the main body center | 140mm |
| Measurement to match between the support and the main body | Φ76mm |
| Diameter of the centerworking stage | Φ95mm |
| Illumination | The down illuminator is the transmitted illumination of the fluorescent lamp(5W),the up illuminator is the reflected illumination of the halogen lamp(6V、10W). |
| Accessories | Kinds of stands and holders |
Optical Specification:
| Objective | Eyepiece | Working Distance | |||||
| WF10X/20mm | WF15X/15mm | WF20X/10mm | |||||
| Total Magnification | Field of view | Total Magnification | Field of view | Total Magnification | Field of view | ||
| 1x | 10x | 20mm | 15x | 15mm | 20x | 10mm | 100mm |
| 2x | 20x | 10mm | 30x | 7.5mm | 40x | 5mm | 100mm |
| 3x | 30x | 7.5mm | 45x | 5mm | 60x | 3.3mm | 100mm |
| 4x | 40x | 5mm | 60x | 3.3mm | 80x | 2.5mm | 100mm |
Company Features
1. Sinowon Innovation Metrology Manufacture Limited. is internationally considered to be an advanced stereoscopic microscope manufacturer.
2. Sinowon is thriving in this industry for its high quality.
3. Sinowon obeys the operation rule of 'three brand new': new materials, new procedures, new technology. Call!
